Lápidas con columnas cruzadas

La calidad se basa en la precisión

Las placas de sujeción cruzadas ofrecen un espacio libre mínimo para la herramienta, lo que permite que la pieza de trabajo quede cerca del husillo. Además, permiten realizar un mecanizado en tres lados. Según la aplicación, las caras de las esquinas también pueden servir para sujetar piezas. Si no se desea una placa de sujeción de cara lisa, los sistemas de rejilla disponibles para nuestras placas de sujeción cruzadas incluyen rejillas estándar de 2", ranuras en T y rejillas personalizadas.

Características principales

Hay disponibles orificios de rejilla, casquillos e insertos para sistemas de 1/2" y 5/8"

Los insertos roscados y endurecidos permiten la sujeción en cada orificio, a la vez que ofrecen una sustitución rápida y fácil

Los casquillos endurecidos de precisión están colocados con exactitud para garantizar una fácil ubicación junto con una alta resistencia al desgaste

Hay disponibles casquillos de repuesto y kits de insertos con una herramienta de extracción a pedido

¿Conocía nuestras placas de epóxi mineral?

Expansión térmica mínima
Reduce la masa
Impresionante amortiguación de vibraciones
Comparable a la elección tradicional de hierro fundido

Catálogo general

Descubra nuestra línea completa de sujeción de piezas, que incluye placas de sujeción CNC, sistemas de sujeción, socios de Build on the Rock y soluciones de sujeción a medida.

Folleto de capacidades

Nuestro PDF sobre las capacidades de AMROK, que ofrece una breve descripción general de nuestra selección de productos de sujeción de piezas.

Pruebas de Tombstone para evaluar el rendimiento dinámico

Dado que los soportes sostienen la pieza de trabajo durante el mecanizado, su respuesta dinámica forma parte del sistema en su conjunto. El objetivo de este trabajo era medir la dinámica de forma individual y, posteriormente, como parte de la configuración de la máquina. Todas las pruebas fueron realizadas por el Dr. Tony L. Schmitz, profesor de ingeniería mecánica de renombre mundial en la Universidad de Tennessee, Knoxville, y miembro del cuerpo docente del Laboratorio Nacional de Oak Ridge, especializado en investigación sobre máquinas herramienta e ingeniería de fabricación.

Solicitar un presupuesto

Lápidas con columnas cruzadas

Especificaciones técnicas

Descargas CAD: La descarga CAD corresponde a una lápida de una sola cara; todas las medidas están expresadas en pulgadas, salvo que se indique lo contrario, y todos los pesos están en libras e incluyen la placa base.

195

181

Tolerancia	Precisión
Planitud (tumbas y placas)	0,0005 / 12x12
Paralelismo (placas)	0,0005 / 12 Máx. 0,002 en total
Perpendicularidad	0,0008 / 12 Mín. 0,001, Máx. 0,002/48
Acabado de superficie	63 RMS
Espesor de la cara	≤18” = ±.002, >18” = ±.003
Orificios roscados (no acumulativos)	±0,005
Diámetro interior del casquillo de precisión	+0,0013 / +0,0007
Concentricidad de bujes de precisión	0,0001
Agujero del casquillo de precisión o perforado a agujero adyacente	±0,0005
Ubicación del orificio del casquillo de la primera fila con respecto a los puntos de referencia	±0,002
Espaciado entre orificios de buje perforados o de precisión (no acumulativo)	0-10 ±0,0005*, 10-20 ±0,0008, 20-30 ±0,0010, 30-40 ±0,0012

*Para el aluminio, sume un 50 % a estas tolerancias.

Showing 195 of 195 models

Product ID	A (in)	B (in)	B1 (in)	C (in)	D (in)	E (in)	F (in)	G (in)	G1 (in)	Weight (lbs)	Material	Grid Style
AMR-K03030832-16	15.75 (400mm)	3.0	8.000	32.00	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	2.00	-	-	437	Cast Iron	Plain Face
AMR-K03030832-16-50	15.75 (400mm)	3.0	8.000	32.00	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	2.00	3.000	-	437	Cast Iron	UNC 1/2"-13
AMR-K03030832-16-62	15.75 (400mm)	3.0	8.000	32.00	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	2.00	3.000	-	437	Cast Iron	UNC 5/8"-11
AMRE-K03031222-16	15.75 (400mm)	3.2	12.000	21.50	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.500	-	230	Epoxy	UNC 1/2"-13
AMRE-K03031224-16	15.75 (400mm)	3.2	12.000	23.50	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.500	-	245	Epoxy	UNC 1/2"-13
AMRE-K03031226-16	15.75 (400mm)	3.2	12.000	25.50	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.500	-	255	Epoxy	UNC 1/2"-13
AMRE-K03031228-16	15.75 (400mm)	3.2	12.000	27.50	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.500	-	270	Epoxy	UNC 1/2"-13
AMRE-K03031230-16	15.75 (400mm)	3.2	12.000	29.50	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.500	-	280	Epoxy	UNC 1/2"-13
AMRE-K03031232-16	15.75 (400mm)	3.2	12.000	31.50	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.500	-	295	Epoxy	UNC 1/2"-13
AMR-K04041020-16	15.75 (400mm)	4.0	10.000	20.00	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	-	-	410	Cast Iron	Plain Face
AMR-K04041020-16-50	15.75 (400mm)	4.0	10.000	20.00	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	1.000	410	Cast Iron	UNC 1/2"-13
AMR-K04041020-16-62	15.75 (400mm)	4.0	10.000	20.00	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	1.000	410	Cast Iron	UNC 5/8"-11
AMR-K04041024-16	15.75 (400mm)	4.0	10.000	24.00	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	-	-	485	Cast Iron	Plain Face
AMR-K04041024-16-50	15.75 (400mm)	4.0	10.000	24.00	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	1.000	485	Cast Iron	UNC 1/2"-13
AMR-K04041024-16-62	15.75 (400mm)	4.0	10.000	24.00	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	1.000	485	Cast Iron	UNC 5/8"-11
AMR-K04041026-16	15.75 (400mm)	4.0	10.000	26.00	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	-	-	520	Cast Iron	Plain Face
AMR-K04041026-16-50	15.75 (400mm)	4.0	10.000	26.00	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	1.000	520	Cast Iron	UNC 1/2"-13
AMR-K04041026-16-62	15.75 (400mm)	4.0	10.000	26.00	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	1.000	520	Cast Iron	UNC 5/8"-11
AMR-K04041028-16	15.75 (400mm)	4.0	10.000	28.00	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	-	-	555	Cast Iron	Plain Face
AMR-K04041028-16-50	15.75 (400mm)	4.0	10.000	28.00	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	1.000	555	Cast Iron	UNC 1/2"-13
AMR-K04041028-16-62	15.75 (400mm)	4.0	10.000	28.00	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	1.000	555	Cast Iron	UNC 5/8"-11
AMR-K04041426-16	15.75 (400mm)	4.0	14.000	26.00	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	-	-	735	Cast Iron	Plain Face
AMR-K04041426-16-50	15.75 (400mm)	4.0	14.000	26.00	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	1.000	735	Cast Iron	UNC 1/2"-13
AMR-K04041426-16-62	15.75 (400mm)	4.0	14.000	26.00	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	1.000	735	Cast Iron	UNC 5/8"-11
AMR-K05051224-16	15.75 (400mm)	5.0	12.000	24.00	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	-	-	655	Cast Iron	Plain Face
AMR-K05051224-16-50	15.75 (400mm)	5.0	12.000	24.00	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	1.000	655	Cast Iron	UNC 1/2"-13
AMR-K05051224-16-62	15.75 (400mm)	5.0	12.000	24.00	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	1.000	655	Cast Iron	UNC 5/8"-11
AMRE-K05051428-16	15.75 (400mm)	5.2	14.000	27.50	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.500	-	405	Epoxy	UNC 1/2"-13
AMRE-K05051430-16	15.75 (400mm)	5.2	14.000	29.50	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.500	-	425	Epoxy	UNC 1/2"-13
AMR-K06061420-16	15.75 (400mm)	6.0	14.000	20.00	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	-	-	585	Cast Iron	Plain Face
AMR-K06061420-16-50	15.75 (400mm)	6.0	14.000	20.00	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	-	585	Cast Iron	UNC 1/2"-13
AMR-K06061420-16-62	15.75 (400mm)	6.0	14.000	20.00	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	-	585	Cast Iron	UNC 5/8"-11
AMR-K06061424-16	15.75 (400mm)	6.0	14.000	24.00	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	-	-	660	Cast Iron	Plain Face
AMR-K06061424-16-50	15.75 (400mm)	6.0	14.000	24.00	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	-	660	Cast Iron	UNC 1/2"-13
AMR-K06061424-16-62	15.75 (400mm)	6.0	14.000	24.00	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	-	660	Cast Iron	UNC 5/8"-11
AMRE-K07071222-16	15.75 (400mm)	7.2	12.000	21.50	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.500	-	305	Epoxy	UNC 1/2"-13
AMRE-K07071224-16	15.75 (400mm)	7.2	12.000	23.50	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.500	-	325	Epoxy	UNC 1/2"-13
AMRE-K07071226-16	15.75 (400mm)	7.2	12.000	25.50	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.500	-	345	Epoxy	UNC 1/2"-13
AMRE-K07071228-16	15.75 (400mm)	7.2	12.000	27.50	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.500	-	360	Epoxy	UNC 1/2"-13
AMRE-K07071230-16	15.75 (400mm)	7.2	12.000	29.50	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.500	-	380	Epoxy	UNC 1/2"-13
AMRE-K09091428-16	15.75 (400mm)	9.2	14.000	27.50	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.500	-	475	Epoxy	UNC 1/2"-13
AMRE-K09091430-16	15.75 (400mm)	9.2	14.000	29.50	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.500	-	500	Epoxy	UNC 1/2"-13
AMR-K03030832-20	19.69 (500mm)	3.0	8.000	32.00	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	-	-	535	Cast Iron	Plain Face
AMR-K03030832-20-50	19.69 (500mm)	3.0	8.000	32.00	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	-	535	Cast Iron	UNC 1/2"-13
AMR-K03030832-20-62	19.69 (500mm)	3.0	8.000	32.00	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	-	535	Cast Iron	UNC 5/8"-11
AMRE-K03031222-20	19.69 (500mm)	3.2	12.000	21.50	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.500	-	290	Epoxy	UNC 1/2"-13
AMRE-K03031224-20	19.69 (500mm)	3.2	12.000	23.50	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.500	-	305	Epoxy	UNC 1/2"-13
AMRE-K03031226-20	19.69 (500mm)	3.2	12.000	25.50	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.500	-	315	Epoxy	UNC 1/2"-13
AMRE-K03031228-20	19.69 (500mm)	3.2	12.000	27.50	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.500	-	325	Epoxy	UNC 1/2"-13
AMRE-K03031230-20	19.69 (500mm)	3.2	12.000	29.50	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.500	-	340	Epoxy	UNC 1/2"-13
AMRE-K03031232-20	19.69 (500mm)	3.2	12.000	31.50	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.500	-	355	Epoxy	UNC 1/2"-13
AMR-K04041026-20	19.69 (500mm)	4.0	10.000	26.00	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	1.50	-	-	575	Cast Iron	Plain Face
AMR-K04041026-20-50	19.69 (500mm)	4.0	10.000	26.00	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	1.50	3.000	1.000	575	Cast Iron	UNC 1/2"-13
AMR-K04041026-20-62	19.69 (500mm)	4.0	10.000	26.00	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	1.50	3.000	1.000	575	Cast Iron	UNC 5/8"-11
AMR-K04041028-20	19.69 (500mm)	4.0	10.000	28.00	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	-	-	629	Cast Iron	Plain Face
AMR-K04041028-20-50	19.69 (500mm)	4.0	10.000	28.00	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	1.000	629	Cast Iron	UNC 1/2"-13
AMR-K04041028-20-62	19.69 (500mm)	4.0	10.000	28.00	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	1.000	629	Cast Iron	UNC 5/8"-11
AMR-K04041632-20	19.69 (500mm)	4.0	16.000	32.00	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	-	-	995	Cast Iron	Plain Face
AMR-K04041632-20-50	19.69 (500mm)	4.0	16.000	32.00	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	1.000	995	Cast Iron	UNC 1/2"-13
AMR-K04041632-20-62	19.69 (500mm)	4.0	16.000	32.00	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	1.000	995	Cast Iron	UNC 5/8"-11
AMR-K05051228-20	19.69 (500mm)	5.0	12.000	28.00	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	-	-	845	Cast Iron	Plain Face
AMR-K05051228-20-50	19.69 (500mm)	5.0	12.000	28.00	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	1.000	845	Cast Iron	UNC 1/2"-13
AMR-K05051228-20-62	19.69 (500mm)	5.0	12.000	28.00	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	1.000	845	Cast Iron	UNC 5/8"-11
AMRE-K05051428-20	19.69 (500mm)	5.2	14.000	27.50	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.500	-	460	Epoxy	UNC 1/2"-13
AMRE-K05051430-20	19.69 (500mm)	5.2	14.000	29.50	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.500	-	485	Epoxy	UNC 1/2"-13
AMRE-K05051432-20	19.69 (500mm)	5.2	14.000	31.50	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.500	-	505	Epoxy	UNC 1/2"-13
AMRE-K05051434-20	19.69 (500mm)	5.2	14.000	33.50	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.500	-	530	Epoxy	UNC 1/2"-13
AMR-K06061224-20	19.69 (500mm)	6.0	12.000	24.00	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	-	-	685	Cast Iron	Plain Face
AMR-K06061224-20-50	19.69 (500mm)	6.0	12.000	24.00	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	-	685	Cast Iron	UNC 1/2"-13
AMR-K06061224-20-62	19.69 (500mm)	6.0	12.000	24.00	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	-	685	Cast Iron	UNC 5/8"-11
AMR-K06061228-20	19.69 (500mm)	6.0	12.000	28.00	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	-	-	770	Cast Iron	Plain Face
AMR-K06061228-20-50	19.69 (500mm)	6.0	12.000	28.00	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	-	770	Cast Iron	UNC 1/2"-13
AMR-K06061228-20-62	19.69 (500mm)	6.0	12.000	28.00	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	-	770	Cast Iron	UNC 5/8"-11
AMR-K06061232-20	19.69 (500mm)	6.0	12.000	32.00	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	-	-	870	Cast Iron	Plain Face
AMR-K06061232-20-50	19.69 (500mm)	6.0	12.000	32.00	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	-	870	Cast Iron	UNC 1/2"-13
AMR-K06061232-20-62	19.69 (500mm)	6.0	12.000	32.00	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	-	870	Cast Iron	UNC 5/8"-11
AMR-K06061420-20	19.69 (500mm)	6.0	14.000	20.00	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	-	-	655	Cast Iron	Plain Face
AMR-K06061420-20-50	19.69 (500mm)	6.0	14.000	20.00	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	-	655	Cast Iron	UNC 1/2"-13
AMR-K06061420-20-62	19.69 (500mm)	6.0	14.000	20.00	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	-	655	Cast Iron	UNC 5/8"-11
AMR-K06061424-20	19.69 (500mm)	6.0	14.000	24.00	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	-	-	785	Cast Iron	Plain Face
AMR-K06061424-20-50	19.69 (500mm)	6.0	14.000	24.00	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	-	785	Cast Iron	UNC 1/2"-13
AMR-K06061424-20-62	19.69 (500mm)	6.0	14.000	24.00	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	-	785	Cast Iron	UNC 5/8"-11
AMR-K06061428-20	19.69 (500mm)	6.0	14.000	28.00	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	-	-	905	Cast Iron	Plain Face
AMR-K06061428-20-50	19.69 (500mm)	6.0	14.000	28.00	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	-	905	Cast Iron	UNC 1/2"-13
AMR-K06061428-20-62	19.69 (500mm)	6.0	14.000	28.00	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	-	905	Cast Iron	UNC 5/8"-11
AMR-K06061628-20	19.69 (500mm)	6.0	16.000	28.00	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	-	-	960	Cast Iron	Plain Face
AMR-K06061628-20-50	19.69 (500mm)	6.0	16.000	28.00	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	-	960	Cast Iron	UNC 1/2"-13
AMR-K06061628-20-62	19.69 (500mm)	6.0	16.000	28.00	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	-	960	Cast Iron	UNC 5/8"-11
AMRE-K07071222-20	19.69 (500mm)	7.2	12.000	21.50	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.500	-	365	Epoxy	UNC 1/2"-13
AMRE-K07071224-20	19.69 (500mm)	7.2	12.000	23.50	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.500	-	385	Epoxy	UNC 1/2"-13
AMRE-K07071226-20	19.69 (500mm)	7.2	12.000	25.50	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.500	-	400	Epoxy	UNC 1/2"-13
AMRE-K07071228-20	19.69 (500mm)	7.2	12.000	27.60	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.500	-	420	Epoxy	UNC 1/2"-13
AMRE-K07071230-20	19.69 (500mm)	7.2	12.000	29.50	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.500	-	440	Epoxy	UNC 1/2"-13
AMRE-K07071232-20	19.69 (500mm)	7.2	12.000	31.50	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.500	-	455	Epoxy	UNC 1/2"-13
AMRE-K07071628-20	19.69 (500mm)	7.2	16.000	27.50	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.500	-	535	Epoxy	UNC 1/2"-13
AMRE-K07071630-20	19.69 (500mm)	7.2	16.000	29.50	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.500	-	565	Epoxy	UNC 1/2"-13
AMRE-K07071632-20	19.69 (500mm)	7.2	16.000	31.50	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.500	-	590	Epoxy	UNC 1/2"-13
AMRE-K07071634-20	19.69 (500mm)	7.2	16.000	33.50	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.500	-	615	Epoxy	UNC 1/2"-13
AMR-K08081828-20	19.69 (500mm)	8.0	18.000	28.00	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	-	-	1070	Cast Iron	Plain Face
AMR-K08081828-20-50	19.69 (500mm)	8.0	18.000	28.00	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	1.000	1070	Cast Iron	UNC 1/2"-13
AMR-K08081828-20-62	19.69 (500mm)	8.0	18.000	28.00	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	1.000	1070	Cast Iron	UNC 5/8"-11
AMRE-K09091428-20	19.69 (500mm)	9.2	14.000	27.50	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.500	-	535	Epoxy	UNC 1/2"-13
AMRE-K09091430-20	19.69 (500mm)	9.2	14.000	29.50	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.500	-	560	Epoxy	UNC 1/2"-13
AMRE-K09091432-20	19.69 (500mm)	9.2	14.000	31.50	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.500	-	590	Epoxy	UNC 1/2"-13
AMRE-K09091434-20	19.69 (500mm)	9.2	14.000	33.50	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.500	-	615	Epoxy	UNC 1/2"-13
AMRE-K03031222-25	24.80 (630mm)	3.2	12.000	21.50	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.500	-	385	Epoxy	UNC 1/2"-13
AMRE-K03031224-25	24.80 (630mm)	3.2	12.000	23.50	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.500	-	400	Epoxy	UNC 1/2"-13
AMRE-K03031226-25	24.80 (630mm)	3.2	12.000	25.50	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.500	-	410	Epoxy	UNC 1/2"-13
AMRE-K03031228-25	24.80 (630mm)	3.2	12.000	27.50	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.500	-	420	Epoxy	UNC 1/2"-13
AMRE-K03031230-25	24.80 (630mm)	3.2	12.000	29.50	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.500	-	435	Epoxy	UNC 1/2"-13
AMRE-K03031232-25	24.80 (630mm)	3.2	12.000	31.50	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.500	-	450	Epoxy	UNC 1/2"-13
AMR-K04041232-25	24.80 (630mm)	4.0	12.000	32.00	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	1.50	-	-	865	Cast Iron	Plain Face
AMR-K04041232-25-50	24.80 (630mm)	4.0	12.000	32.00	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	1.50	3.000	1.000	865	Cast Iron	UNC 1/2"-13
AMR-K04041232-25-62	24.80 (630mm)	4.0	12.000	32.00	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	1.50	3.000	1.000	865	Cast Iron	UNC 5/8"-11
AMR-K04041236-25	24.80 (630mm)	4.0	12.000	36.00	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	-	-	1055	Cast Iron	Plain Face
AMR-K04041236-25-50	24.80 (630mm)	4.0	12.000	36.00	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	1.000	1055	Cast Iron	UNC 1/2"-13
AMR-K04041236-25-62	24.80 (630mm)	4.0	12.000	36.00	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	1.000	1055	Cast Iron	UNC 5/8"-11
AMR-K04041632-25	24.80 (630mm)	4.0	16.000	32.00	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	-	-	1225	Cast Iron	Plain Face
AMR-K04041632-25-50	24.80 (630mm)	4.0	16.000	32.00	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	1.000	1225	Cast Iron	UNC 1/2"-13
AMR-K04041632-25-62	24.80 (630mm)	4.0	16.000	32.00	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	1.000	1225	Cast Iron	UNC 5/8"-11
AMRE-K05051428-25	24.80 (630mm)	5.2	14.000	27.50	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.500	-	555	Epoxy	UNC 1/2"-13
AMRE-K05051430-25	24.80 (630mm)	5.2	14.000	29.50	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.500	-	580	Epoxy	UNC 1/2"-13
AMRE-K05051432-25	24.80 (630mm)	5.2	14.000	31.50	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.500	-	600	Epoxy	UNC 1/2"-13
AMRE-K05051434-25	24.80 (630mm)	5.2	14.000	33.50	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.500	-	625	Epoxy	UNC 1/2"-13
AMRE-K05051436-25	24.80 (630mm)	5.2	14.000	35.50	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.500	-	645	Epoxy	UNC 1/2"-13
AMRE-K05051438-25	24.80 (630mm)	5.2	14.000	37.50	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.500	-	670	Epoxy	UNC 1/2"-13
AMR-K06061628-25	24.80 (630mm)	6.0	16.000	28.00	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	-	-	1145	Cast Iron	Plain Face
AMR-K06061628-25-50	24.80 (630mm)	6.0	16.000	28.00	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	-	1145	Cast Iron	UNC 1/2"-13
AMR-K06061628-25-62	24.80 (630mm)	6.0	16.000	28.00	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	-	1145	Cast Iron	UNC 5/8"-11
AMR-K06061630-25	24.80 (630mm)	6.0	16.000	30.00	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	-	-	1205	Cast Iron	Plain Face
AMR-K06061630-25-50	24.80 (630mm)	6.0	16.000	30.00	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	-	1205	Cast Iron	UNC 1/2"-13
AMR-K06061630-25-62	24.80 (630mm)	6.0	16.000	30.00	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	-	1205	Cast Iron	UNC 5/8"-11
AMR-K06061632-25	24.80 (630mm)	6.0	16.000	32.00	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	-	-	1195	Cast Iron	Plain Face
AMR-K06061632-25-50	24.80 (630mm)	6.0	16.000	32.00	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	-	1195	Cast Iron	UNC 1/2"-13
AMR-K06061632-25-62	24.80 (630mm)	6.0	16.000	32.00	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	-	1195	Cast Iron	UNC 5/8"-11
AMRE-K07071222-25	24.80 (630mm)	7.2	12.000	21.50	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.500	-	460	Epoxy	UNC 1/2"-13
AMRE-K07071224-25	24.80 (630mm)	7.2	12.000	23.50	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.500	-	480	Epoxy	UNC 1/2"-13
AMRE-K07071226-25	24.80 (630mm)	7.2	12.000	25.50	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.500	-	495	Epoxy	UNC 1/2"-13
AMRE-K07071228-25	24.80 (630mm)	7.2	12.000	27.50	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.500	-	515	Epoxy	UNC 1/2"-13
AMRE-K07071230-25	24.80 (630mm)	7.2	12.000	28.50	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.500	-	535	Epoxy	UNC 1/2"-13
AMRE-K07071232-25	24.80 (630mm)	7.2	12.000	31.50	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.500	-	550	Epoxy	UNC 1/2"-13
AMRE-K07071628-25	24.80 (630mm)	7.2	16.000	27.50	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.500	-	630	Epoxy	UNC 1/2"-13
AMRE-K07071630-25	24.80 (630mm)	7.2	16.000	29.50	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.500	-	660	Epoxy	UNC 1/2"-13
AMRE-K07071632-25	24.80 (630mm)	7.2	16.000	31.50	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.500	-	685	Epoxy	UNC 1/2"-13
AMRE-K07071634-25	24.80 (630mm)	7.2	16.000	33.50	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.500	-	710	Epoxy	UNC 1/2"-13
AMRE-K07071636-25	24.80 (630mm)	7.2	16.000	35.50	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.500	-	740	Epoxy	UNC 1/2"-13
AMRE-K07071638-25	24.80 (630mm)	7.2	16.000	37.50	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.500	-	765	Epoxy	UNC 1/2"-13
AMR-K08081832-25	24.80 (630mm)	8.0	18.000	32.00	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	-	-	1320	Cast Iron	Plain Face
AMR-K08081832-25-50	24.80 (630mm)	8.0	18.000	32.00	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	1.000	1320	Cast Iron	UNC 1/2"-13
AMR-K08081832-25-62	24.80 (630mm)	8.0	18.000	32.00	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	1.000	1320	Cast Iron	UNC 5/8"-11
AMR-K08081836-25	24.80 (630mm)	8.0	18.000	36.00	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	-	-	1565	Cast Iron	Plain Face
AMR-K08081836-25-50	24.80 (630mm)	8.0	18.000	36.00	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	1.000	1565	Cast Iron	UNC 1/2"-13
AMR-K08081836-25-62	24.80 (630mm)	8.0	18.000	36.00	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	1.000	1565	Cast Iron	UNC 5/8"-11
AMRE-K09091428-25	24.80 (630mm)	9.2	14.000	27.50	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.500	-	630	Epoxy	UNC 1/2"-13
AMRE-K09091430-25	24.80 (630mm)	9.2	14.000	29.50	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.500	-	560	Epoxy	UNC 1/2"-13
AMRE-K09091432-25	24.80 (630mm)	9.2	14.000	31.50	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.500	-	685	Epoxy	UNC 1/2"-13
AMRE-K09091434-25	24.80 (630mm)	9.2	14.000	33.50	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.500	-	710	Epoxy	UNC 1/2"-13
AMRE-K0909438-25	24.80 (630mm)	9.2	14.000	37.50	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.500	-	765	Epoxy	UNC 1/2"-13
AMR-K10102236-25	24.80 (630mm)	10.0	22.000	36.00	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	-	-	1880	Cast Iron	Plain Face
AMR-K10102236-25-50	24.80 (630mm)	10.0	22.000	36.00	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	-	1880	Cast Iron	UNC 1/2"-13
AMR-K10102236-25-62	24.80 (630mm)	10.0	22.000	36.00	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	-	1880	Cast Iron	UNC 5/8"-11
AMRE-K05051428-32	31.50 (800mm)	5.2	14.000	27.50	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	2.00	3.500	-	710	Epoxy	UNC 1/2"-13
AMRE-K05051430-32	31.50 (800mm)	5.2	14.000	29.50	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	2.00	3.500	-	735	Epoxy	UNC 1/2"-13
AMRE-K05051432-32	31.50 (800mm)	5.2	14.000	31.50	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	2.00	3.500	-	755	Epoxy	UNC 1/2"-13
AMRE-K05051434-32	31.50 (800mm)	5.2	14.000	33.50	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	2.00	3.500	-	780	Epoxy	UNC 1/2"-13
AMRE-K05051436-32	31.50 (800mm)	5.2	14.000	35.50	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	2.00	3.500	-	800	Epoxy	UNC 1/2"-13
AMRE-K05051438-32	31.50 (800mm)	5.2	14.000	37.50	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	2.00	3.500	-	825	Epoxy	UNC 1/2"-13
AMRE-K05051440-32	31.50 (800mm)	5.2	14.000	39.50	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	2.00	3.500	-	845	Epoxy	UNC 1/2"-13
AMRE-K07071222-32	31.50 (800mm)	7.2	12.000	21.50	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	2.00	3.500	-	615	Epoxy	UNC 1/2"-13
AMRE-K07071224-32	31.50 (800mm)	7.2	12.000	23.50	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	2.00	3.500	-	635	Epoxy	UNC 1/2"-13
AMRE-K07071226-32	31.50 (800mm)	7.2	12.000	25.50	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	2.00	3.500	-	650	Epoxy	UNC 1/2"-13
AMRE-K07071228-32	31.50 (800mm)	7.2	12.000	27.50	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	2.00	3.500	-	670	Epoxy	UNC 1/2"-13
AMRE-K07071230-32	31.50 (800mm)	7.2	12.000	29.50	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	2.00	3.500	-	690	Epoxy	UNC 1/2"-13
AMRE-K07071232-30	31.50 (800mm)	7.2	12.000	31.50	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	2.00	3.500	-	705	Epoxy	UNC 1/2"-13
AMRE-K07071628-32	31.50 (800mm)	7.2	16.000	27.50	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	2.00	3.500	-	785	Epoxy	UNC 1/2"-13
AMRE-K07071630-32	31.50 (800mm)	7.2	16.000	29.50	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	2.00	3.500	-	815	Epoxy	UNC 1/2"-13
AMRE-K07071632-32	31.50 (800mm)	7.2	16.000	31.50	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	2.00	3.500	-	840	Epoxy	UNC 1/2"-13
AMRE-K07071634-32	31.50 (800mm)	7.2	16.000	33.50	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	2.00	3.500	-	865	Epoxy	UNC 1/2"-13
AMRE-K07071636-62	31.50 (800mm)	7.2	16.000	35.50	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	2.00	3.500	-	895	Epoxy	UNC 1/2"-13
AMRE-K07071638-32	31.50 (800mm)	7.2	16.000	37.50	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	2.00	3.500	-	920	Epoxy	UNC 1/2"-13
AMRE-K07071640-32	31.50 (800mm)	7.2	16.000	39.50	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	2.00	3.500	-	945	Epoxy	UNC 1/2"-13
AMRE-K09091428-32	31.50 (800mm)	9.2	14.000	27.50	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	2.00	3.500	-	785	Epoxy	UNC 1/2"-13
AMRE-K09091430-32	31.50 (800mm)	9.2	14.000	29.50	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	2.00	3.500	-	810	Epoxy	UNC 1/2"-13
AMRE-K09091432-32	31.50 (800mm)	9.2	14.000	31.50	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	2.00	3.500	-	840	Epoxy	UNC 1/2"-13
AMRE-K09091434-32	31.50 (800mm)	9.2	14.000	33.50	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	2.00	3.500	-	865	Epoxy	UNC 1/2"-13
AMRE-K09091436-25	31.50 (800mm)	9.2	14.000	33.50	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	2.00	3.500	-	740	Epoxy	UNC 1/2"-13
AMRE-K09091436-32	31.50 (800mm)	9.2	14.000	35.50	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	2.00	3.500	-	895	Epoxy	UNC 1/2"-13
AMRE-K09091438-32	31.50 (800mm)	9.2	14.000	37.50	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	2.00	3.500	-	920	Epoxy	UNC 1/2"-13
AMRE-K09091440-32	31.50 (800mm)	9.2	14.000	39.50	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	2.00	3.500	-	945	Epoxy	UNC 1/2"-13
AMR-K10102236-32	31.50 (800mm)	10.0	22.000	36.00	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	2.00	-	-	2060	Cast Iron	Plain Face
AMR-K10102236-32-50	31.50 (800mm)	10.0	22.000	36.00	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	2.00	3.000	-	2060	Cast Iron	UNC 1/2"-13
AMR-K10102236-32-62	31.50 (800mm)	10.0	22.000	36.00	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	2.00	3.000	-	2060	Cast Iron	UNC 5/8"-11
AMR-K10102240-32	31.50 (800mm)	10.0	22.000	40.00	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	2.00	-	-	2265	Cast Iron	Plain Face
AMR-K10102240-32-50	31.50 (800mm)	10.0	22.000	40.00	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	2.00	3.000	-	2265	Cast Iron	UNC 1/2"-13
AMR-K10102240-32-62	31.50 (800mm)	10.0	22.000	40.00	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	2.00	3.000	-	2265	Cast Iron	UNC 5/8"-11

0 models selected

Your Selection

Each model below is routed to the best next step based on availability.

Calculadora del tiempo de preparación

¿Cuánto cuesta el tiempo de configuración? ¿Te está saliendo caro?

Cada cambio implica tiempo de inactividad del husillo. Los sistemas de sujeción multipieza reducen drásticamente la frecuencia de los ajustes, por lo que tus máquinas pasan más horas cortando y menos tiempo esperando.

Tus máquinas

Máquinas CNC

Valor de la máquina por hora

El problema de la configuración

Cambios / Día / Máquina

Promedio de minutos por cambio

min

Establecer el objetivo de reducción

Costo anual de los cambios de decorado

1,500 hrs

Horas de funcionamiento del torno perdidas por la configuración / Año

$263K

Valor anual de la producción perdida

$131K

Recuperable con sujeción de piezas

Ver desglose completo del ROI

Based on 250 working days/yr. Multi-part fixturing reduces changeover frequency so your spindle spends more time cutting.

Desde el Centro de recursos

Contenido relacionado

Tombstone CNC de AMROK con sistema de sujeción SCHUNK VERO-S

1 min 51 sec

Videos Workholding Product Selection

Tombstone CNC de AMROK con sistema de sujeción SCHUNK VERO-S

Al combinar los productos de sujeción de AMROK y Schunk, una placa de sujeción CNC de AMROK mecanizada especialmente puede alojar los soportes de fijación de punto cero Vero-S de Schunk. Con un diseño autoblocante accionado por resorte y una instalación de pasadores en un ángulo de hasta 23 grados, los soportes Vero-S son capaces de reducir el tiempo de configuración en casi un 90 %.

Ver todos los recursos

Entrega de palés de WorkFlow

Slytek Software

AMROK Select

Tu pieza → Nuestro diseño → Mobiliario llave en mano

VariFlow

Serie MistFlow

El software de monitoreo CNC mejora el tiempo de actividad con los recursos existentes

Hennig entra en la lista INC5000 de 2025 en un momento en que el sector manufacturero estadounidense vuelve a apostar por la fiabilidad

Cubiertas para la caja de las camionetas de trabajo: la próxima mejora imprescindible para tu flota

Cubiertas de foso de seguridad

Puertas enrollables para camiones de trabajo

Cajas para generadores y soluciones de protección eléctrica

Cierre hidráulico de varilla RCHX

Fabricación por encargo

El software de monitoreo CNC mejora el tiempo de actividad con los recursos existentes

Hennig entra en la lista INC5000 de 2025 en un momento en que el sector manufacturero estadounidense vuelve a apostar por la fiabilidad

Cubiertas para la caja de las camionetas de trabajo: la próxima mejora imprescindible para tu flota

Aeroespacial y defensa

Automatización del mecanizado

Máquina herramienta CNC

Prensado y estampado

Vehículos de motor y vehículos utilitarios

Acerías y producción metalúrgica

Lápidas con columnas cruzadas

La calidad se basa en la precisión

¿Conocía nuestras placas de epóxi mineral?

Especificaciones técnicas

Your Selection

¿Cuánto cuesta el tiempo de configuración? ¿Te está saliendo caro?

Contenido relacionado

Tombstone CNC de AMROK con sistema de sujeción SCHUNK VERO-S
