Lápida cúbica

La calidad se basa en la precisión

Las placas de sujeción cúbicas resultan útiles cuando se necesita una superficie más amplia y permiten el mecanizado en los cuatro lados. Si no se desea una placa de sujeción de cara lisa, los sistemas de rejilla disponibles para nuestras placas cúbicas incluyen la rejilla estándar de 2 pulgadas, ranuras en T y rejillas personalizadas.

Características principales

Hay orificios de rejilla, casquillos e insertos disponibles tanto para sistemas de 1/2" como de 5/8"

Los insertos roscados y endurecidos permiten la sujeción en cada orificio, a la vez que ofrecen una sustitución rápida y sencilla

Los casquillos endurecidos de precisión están colocados con exactitud para garantizar una fácil ubicación junto con una alta resistencia al desgaste

Hay disponibles casquillos de repuesto y kits de insertos con una herramienta de extracción a pedido

¿Conocía nuestras placas de epóxi mineral?

Expansión térmica mínima
Reduce la masa
Impresionante amortiguación de vibraciones
Comparable a la elección tradicional de materiales de hierro fundido

Catálogo general

Descubra nuestra línea completa de sujeción de piezas, que incluye placas de sujeción CNC, sistemas de sujeción, socios de Build on the Rock y soluciones de sujeción a medida.

Folleto de capacidades

Nuestro folleto en PDF sobre las capacidades reducidas de AMROK, que ofrece una breve descripción general de nuestra selección de productos de sujeción de piezas.

Pruebas de Tombstone para evaluar el rendimiento dinámico

Dado que los soportes sostienen la pieza de trabajo durante el mecanizado, su respuesta dinámica forma parte del sistema en su conjunto. El objetivo de este trabajo era medir la dinámica de forma individual y, posteriormente, como parte de la configuración de la máquina. Todas las pruebas fueron realizadas por el Dr. Tony L. Schmitz, profesor de ingeniería mecánica de renombre mundial en la Universidad de Tennessee, Knoxville, y miembro del cuerpo docente del Laboratorio Nacional de Oak Ridge, especializado en investigación sobre máquinas herramienta e ingeniería de fabricación.

Solicitar un presupuesto

Lápida cúbica

Especificaciones técnicas

Descargas CAD: La descarga CAD corresponde a una lápida de una sola cara; todas las medidas están expresadas en pulgadas, salvo que se indique lo contrario, y todos los pesos están en libras e incluyen la placa base.

369

303

Tolerancia	Precisión
Planitud (tumbas y placas)	0,0005 / 12x12
Paralelismo (placas)	0,0005 / 12 Máx. 0,002 en total
Perpendicularidad	0,0008 / 12 Mín. 0,001, Máx. 0,002/48
Acabado de superficie	63 RMS
Espesor de la cara	≤18” = ±.002, >18” = ±.003
Orificios roscados (no acumulativos)	±0,005
Diámetro interior del casquillo de precisión	+0,0013 / +0,0007
Concentricidad de bujes de precisión	0,0001
Agujero del casquillo de precisión o perforado a agujero adyacente	±0,0005
Ubicación del orificio del casquillo de la primera fila con respecto a los puntos de referencia	±0,002
Espaciado entre orificios de buje perforados o de precisión (no acumulativo)	0-10 ±0,0005*, 10-20 ±0,0008, 20-30 ±0,0010, 30-40 ±0,0012

*Para el aluminio, sume un 50 % a estas tolerancias.

Showing 369 of 369 models

Product ID	A (in)	B (in)	B1 (in)	C (in)	D (in)	E (in)	F (in)	G (in)	Weight (lbs)	Material	Grid Style
AMR-C060620-12	11.81 (300mm)	6.000	6.000	20.0	Upon Request	Upon Request	1.50	-	210	Cast Iron	Plain Face
AMR-C060620-12-50	11.81 (300mm)	6.000	6.000	20.0	Upon Request	Upon Request	1.50	3.000	210	Cast Iron	UNC 1/2"-13
AMR-C060620-12-62	11.81 (300mm)	6.000	6.000	20.0	Upon Request	Upon Request	1.50	3.000	210	Cast Iron	UNC 5/8-13"
AMR-C060820-12	11.81 (300mm)	6.000	8.000	20.0	Upon Request	Upon Request	1.50	-	250	Cast Iron	Plain Face
AMR-C060820-12-50	11.81 (300mm)	6.000	8.000	20.0	Upon Request	Upon Request	1.50	3.000	250	Cast Iron	UNC 1/2"-13
AMR-C060820-12-62	11.81 (300mm)	6.000	8.000	20.0	Upon Request	Upon Request	1.50	3.000	250	Cast Iron	UNC 5/8-13"
AMR-C080818-12	11.81 (300mm)	8.000	8.000	18.0	Upon Request	Upon Request	2.00	-	275	Cast Iron	Plain Face
AMR-C080818-12-50	11.81 (300mm)	8.000	8.000	18.0	Upon Request	Upon Request	2.00	3.000	275	Cast Iron	UNC 1/2"-13
AMR-C080818-12-62	11.81 (300mm)	8.000	8.000	18.0	Upon Request	Upon Request	2.00	3.000	275	Cast Iron	UNC 5/8-13"
AMRE-C080820-12	11.81 (300mm)	8.000	8.000	19.5	Upon Request	Upon Request	1.50	3.000	200	Epoxy	UNC 1/2"-13
AMRE-C080822-12	11.81 (300mm)	8.000	8.000	21.5	Upon Request	Upon Request	1.50	3.000	215	Epoxy	UNC 1/2"-13
AMRE-C080824-12	11.81 (300mm)	8.000	8.000	23.5	Upon Request	Upon Request	1.50	3.000	231	Epoxy	UNC 1/2"-13
AMRE-C080826-12	11.81 (300mm)	8.000	8.000	25.5	Upon Request	Upon Request	1.50	3.000	245	Epoxy	UNC 1/2"-13
AMR-C081020-12	11.81 (300mm)	8.000	10.000	20.0	Upon Request	Upon Request	1.50	-	325	Cast Iron	Plain Face
AMR-C081020-12-50	11.81 (300mm)	8.000	10.000	20.0	Upon Request	Upon Request	1.50	3.000	325	Cast Iron	UNC 1/2"-13
AMR-C081020-12-62	11.81 (300mm)	8.000	10.000	20.0	Upon Request	Upon Request	1.50	3.000	325	Cast Iron	UNC 5/8-13"
AMR-C060620-16	15.75 (400mm)	6.000	6.000	20.0	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	-	265	Cast Iron	Plain Face
AMR-C060620-16-50	15.75 (400mm)	6.000	6.000	20.0	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	265	Cast Iron	UNC 1/2"-13
AMR-C060620-16-62	15.75 (400mm)	6.000	6.000	20.0	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	265	Cast Iron	UNC 5/8-13"
AMR-C060624-16	15.75 (400mm)	6.000	6.000	24.0	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	-	285	Cast Iron	Plain Face
AMR-C060624-16-50	15.75 (400mm)	6.000	6.000	24.0	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	285	Cast Iron	UNC 1/2"-13
AMR-C060624-16-62	15.75 (400mm)	6.000	6.000	24.0	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	285	Cast Iron	UNC 5/8-13"
AMR-C060824-16	15.75 (400mm)	6.000	8.000	24.0	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	-	335	Cast Iron	Plain Face
AMR-C060824-16-50	15.75 (400mm)	6.000	8.000	24.0	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	335	Cast Iron	UNC 1/2"-13
AMR-C060824-16-62	15.75 (400mm)	6.000	8.000	24.0	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	335	Cast Iron	UNC 5/8-13"
AMR-C060826-16	15.75 (400mm)	6.000	8.000	26.0	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	-	360	Cast Iron	Plain Face
AMR-C060826-16-50	15.75 (400mm)	6.000	8.000	26.0	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	360	Cast Iron	UNC 1/2"-13
AMR-C060826-16-62	15.75 (400mm)	6.000	8.000	26.0	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	360	Cast Iron	UNC 5/8-13"
AMR-C061224-16	15.75 (400mm)	6.000	12.000	24.0	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	-	425	Cast Iron	Plain Face
AMR-C061224-16-50	15.75 (400mm)	6.000	12.000	24.0	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	425	Cast Iron	UNC 1/2"-13
AMR-C061224-16-62	15.75 (400mm)	6.000	12.000	24.0	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	425	Cast Iron	UNC 5/8-13"
AMR-C080818-16	15.75 (400mm)	8.000	8.000	18.0	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	2.00	-	265	Cast Iron	Plain Face
AMR-C080818-16-50	15.75 (400mm)	8.000	8.000	18.0	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	2.00	3.000	265	Cast Iron	UNC 1/2"-13
AMR-C080818-16-62	15.75 (400mm)	8.000	8.000	18.0	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	2.00	3.000	265	Cast Iron	UNC 5/8-13"
AMRE-C080820-16	15.75 (400mm)	8.000	8.000	19.5	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	240	Epoxy	UNC 1/2"-13
AMR-C080820-16	15.75 (400mm)	8.000	8.000	20.0	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	-	330	Cast Iron	Plain Face
AMR-C080820-16-50	15.75 (400mm)	8.000	8.000	20.0	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	330	Cast Iron	UNC 1/2"-13
AMR-C080820-16-62	15.75 (400mm)	8.000	8.000	20.0	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	330	Cast Iron	UNC 5/8-13"
AMRE-C080822-16	15.75 (400mm)	8.000	8.000	21.5	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	260	Epoxy	UNC 1/2"-13
AMR-C080822-16	15.75 (400mm)	8.000	8.000	22.0	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	2.00	-	380	Cast Iron	Plain Face
AMR-C080822-16-50	15.75 (400mm)	8.000	8.000	22.0	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	2.00	3.000	380	Cast Iron	UNC 1/2"-13
AMR-C080822-16-62	15.75 (400mm)	8.000	8.000	22.0	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	2.00	3.000	380	Cast Iron	UNC 5/8-13"
AMRE-C080824-16	15.75 (400mm)	8.000	8.000	23.5	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	275	Epoxy	UNC 1/2"-13
AMR-C080824-16	15.75 (400mm)	8.000	8.000	24.0	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	-	405	Cast Iron	Plain Face
AMR-C080824-16-50	15.75 (400mm)	8.000	8.000	24.0	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	405	Cast Iron	UNC 1/2"-13
AMR-C080824-16-62	15.75 (400mm)	8.000	8.000	24.0	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	405	Cast Iron	UNC 5/8-13"
AMRE-C080826-16	15.75 (400mm)	8.000	8.000	25.5	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	290	Epoxy	UNC 1/2"-13
AMR-C080826-16	15.75 (400mm)	8.000	8.000	26.0	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	-	440	Cast Iron	Plain Face
AMR-C080826-16-50	15.75 (400mm)	8.000	8.000	26.0	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	440	Cast Iron	UNC 1/2"-13
AMR-C080826-16-62	15.75 (400mm)	8.000	8.000	26.0	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	440	Cast Iron	UNC 5/8-13"
AMR-C080828-16	15.75 (400mm)	8.000	8.000	28.0	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	-	455	Cast Iron	Plain Face
AMR-C080828-16-50	15.75 (400mm)	8.000	8.000	28.0	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	455	Cast Iron	UNC 1/2"-13
AMR-C080828-16-62	15.75 (400mm)	8.000	8.000	28.0	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	455	Cast Iron	UNC 5/8-13"
AMR-C081024-16	15.75 (400mm)	8.000	10.000	24.0	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	-	430	Cast Iron	Plain Face
AMR-C081024-16-50	15.75 (400mm)	8.000	10.000	24.0	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	430	Cast Iron	UNC 1/2"-13
AMR-C081024-16-62	15.75 (400mm)	8.000	10.000	24.0	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	430	Cast Iron	UNC 5/8-13"
AMR-C081224-16	15.75 (400mm)	8.000	12.000	24.0	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	-	480	Cast Iron	Plain Face
AMR-C081224-16-50	15.75 (400mm)	8.000	12.000	24.0	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	480	Cast Iron	UNC 1/2"-13
AMR-C081224-16-62	15.75 (400mm)	8.000	12.000	24.0	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	480	Cast Iron	UNC 5/8-13"
AMR-C101018-16	15.75 (400mm)	10.000	10.000	18.0	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	-	375	Cast Iron	Plain Face
AMR-C101018-16-50	15.75 (400mm)	10.000	10.000	18.0	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	375	Cast Iron	UNC 1/2"-13
AMR-C101018-16-62	15.75 (400mm)	10.000	10.000	18.0	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	375	Cast Iron	UNC 5/8-13"
AMR-C101021-16	15.75 (400mm)	10.000	10.000	20.5	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	2.00	-	440	Cast Iron	Plain Face
AMR-C101021-16-50	15.75 (400mm)	10.000	10.000	20.5	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	2.00	3.000	440	Cast Iron	UNC 1/2"-13
AMR-C101021-16-62	15.75 (400mm)	10.000	10.000	20.5	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	2.00	3.000	440	Cast Iron	UNC 5/8-13"
AMR-C101024-16	15.75 (400mm)	10.000	10.000	24.0	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	-	475	Cast Iron	Plain Face
AMR-C101024-16-50	15.75 (400mm)	10.000	10.000	24.0	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	475	Cast Iron	UNC 1/2"-13
AMR-C101024-16-62	15.75 (400mm)	10.000	10.000	24.0	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	475	Cast Iron	UNC 5/8-13"
AMRE-C101026-16	15.75 (400mm)	10.000	10.000	25.5	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	370	Epoxy	UNC 1/2"-13
AMR-C101026-16	15.75 (400mm)	10.000	10.000	26.0	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	-	520	Cast Iron	Plain Face
AMR-C101026-16-50	15.75 (400mm)	10.000	10.000	26.0	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	520	Cast Iron	UNC 1/2"-13
AMR-C101026-16-62	15.75 (400mm)	10.000	10.000	26.0	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	520	Cast Iron	UNC 5/8-13"
AMRE-C101028-16	15.75 (400mm)	10.000	10.000	27.5	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	390	Epoxy	UNC 1/2"-13
AMR-C101028-16	15.75 (400mm)	10.000	10.000	28.0	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	-	540	Cast Iron	Plain Face
AMR-C101028-16-50	15.75 (400mm)	10.000	10.000	28.0	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	540	Cast Iron	UNC 1/2"-13
AMR-C101028-16-62	15.75 (400mm)	10.000	10.000	28.0	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	540	Cast Iron	UNC 5/8-13"
AMRE-C101030-16	15.75 (400mm)	10.000	10.000	29.5	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	410	Epoxy	UNC 1/2"-13
AMRE-C101032-16	15.75 (400mm)	10.000	10.000	31.5	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	435	Epoxy	UNC 1/2"-13
AMRE-C101034-16	15.75 (400mm)	10.000	10.000	33.5	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	455	Epoxy	UNC 1/2"-13
AMR-C121218-16	15.75 (400mm)	12.000	12.000	18.0	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	-	440	Cast Iron	Plain Face
AMR-C121218-16-50	15.75 (400mm)	12.000	12.000	18.0	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	440	Cast Iron	UNC 1/2"-13
AMR-C121218-16-62	15.75 (400mm)	12.000	12.000	18.0	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	440	Cast Iron	UNC 5/8-13"
AMRE-C121222-16	15.75 (400mm)	12.000	12.000	21.5	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	360	Epoxy	UNC 1/2"-13
AMRE-C121224-16	15.75 (400mm)	12.000	12.000	23.5	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	385	Epoxy	UNC 1/2"-13
AMR-C121224-16	15.75 (400mm)	12.000	12.000	24.0	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	-	590	Cast Iron	Plain Face
AMR-C121224-16-50	15.75 (400mm)	12.000	12.000	24.0	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	590	Cast Iron	UNC 1/2"-13
AMR-C121224-16-62	15.75 (400mm)	12.000	12.000	24.0	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	590	Cast Iron	UNC 5/8-13"
AMRE-C121226-16	15.75 (400mm)	12.000	12.000	25.5	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	410	Epoxy	UNC 1/2"-13
AMRE-C121228-16	15.75 (400mm)	12.000	12.000	27.5	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	435	Epoxy	UNC 1/2"-13
AMR-C121228-16	15.75 (400mm)	12.000	12.000	28.0	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	-	670	Cast Iron	Plain Face
AMR-C121228-16-50	15.75 (400mm)	12.000	12.000	28.0	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	670	Cast Iron	UNC 1/2"-13
AMR-C121228-16-62	15.75 (400mm)	12.000	12.000	28.0	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	670	Cast Iron	UNC 5/8-13"
AMRE-C121230-16	15.75 (400mm)	12.000	12.000	29.5	11.811 (300mm) to 12.598 (320mm)	4.331 (110mm)	1.50	3.000	460	Epoxy	UNC 1/2"-13
AMRE-C080820-20	19.69 (500mm)	8.000	8.000	19.5	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	1.50	3.000	205	Epoxy	UNC 1/2"-13
AMRE-C080822-20	19.69 (500mm)	8.000	8.000	21.5	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	1.50	3.000	320	Epoxy	UNC 1/2"-13
AMRE-C080824-20	19.69 (500mm)	8.000	8.000	23.5	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	1.50	3.000	335	Epoxy	UNC 1/2"-13
AMR-C080824-20	19.69 (500mm)	8.000	8.000	24.0	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	-	485	Cast Iron	Plain Face
AMR-C080824-20-50	19.69 (500mm)	8.000	8.000	24.0	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	485	Cast Iron	UNC 1/2"-13
AMR-C080824-20-62	19.69 (500mm)	8.000	8.000	24.0	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	485	Cast Iron	UNC 5/8-13"
AMRE-C080826-20	19.69 (500mm)	8.000	8.000	25.5	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	1.50	3.000	350	Epoxy	UNC 1/2"-13
AMR-C080826-20	19.69 (500mm)	8.000	8.000	26.0	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	-	510	Cast Iron	Plain Face
AMR-C080826-20-50	19.69 (500mm)	8.000	8.000	26.0	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	510	Cast Iron	UNC 1/2"-13
AMR-C080826-20-62	19.69 (500mm)	8.000	8.000	26.0	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	510	Cast Iron	UNC 5/8-13"
AMR-C080828-20	19.69 (500mm)	8.000	8.000	28.0	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	-	540	Cast Iron	Plain Face
AMR-C080828-20-50	19.69 (500mm)	8.000	8.000	28.0	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	540	Cast Iron	UNC 1/2"-13
AMR-C080828-20-62	19.69 (500mm)	8.000	8.000	28.0	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	540	Cast Iron	UNC 5/8-13"
AMR-C081221-20	19.69 (500mm)	8.000	12.000	20.5	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	-	510	Cast Iron	Plain Face
AMR-C081221-20-50	19.69 (500mm)	8.000	12.000	20.5	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	510	Cast Iron	UNC 1/2"-13
AMR-C081221-20-62	19.69 (500mm)	8.000	12.000	20.5	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	510	Cast Iron	UNC 5/8-13"
AMR-C081224-20	19.69 (500mm)	8.000	12.000	24.0	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	-	570	Cast Iron	Plain Face
AMR-C081224-20-50	19.69 (500mm)	8.000	12.000	24.0	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	570	Cast Iron	UNC 1/2"-13
AMR-C081224-20-62	19.69 (500mm)	8.000	12.000	24.0	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	570	Cast Iron	UNC 5/8-13"
AMR-C081630-20	19.69 (500mm)	8.000	16.000	30.0	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	-	785	Cast Iron	Plain Face
AMR-C081630-20-50	19.69 (500mm)	8.000	16.000	30.0	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	785	Cast Iron	UNC 1/2"-13
AMR-C081630-20-62	19.69 (500mm)	8.000	16.000	30.0	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	785	Cast Iron	UNC 5/8-13"
AMR-C090924-20	19.69 (500mm)	9.000	9.000	24.0	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	-	535	Cast Iron	Plain Face
AMR-C090924-20-50	19.69 (500mm)	9.000	9.000	24.0	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	535	Cast Iron	UNC 1/2"-13
AMR-C090924-20-62	19.69 (500mm)	9.000	9.000	24.0	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	535	Cast Iron	UNC 5/8-13"
AMR-C101020-20	19.69 (500mm)	10.000	10.000	20.0	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	-	474	Cast Iron	Plain Face
AMR-C101020-20-50	19.69 (500mm)	10.000	10.000	20.0	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	474	Cast Iron	UNC 1/2"-13
AMR-C101020-20-62	19.69 (500mm)	10.000	10.000	20.0	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	474	Cast Iron	UNC 5/8-13"
AMR-C101024-20	19.69 (500mm)	10.000	10.000	24.0	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	-	570	Cast Iron	Plain Face
AMR-C101024-20-50	19.69 (500mm)	10.000	10.000	24.0	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	570	Cast Iron	UNC 1/2"-13
AMR-C101024-20-62	19.69 (500mm)	10.000	10.000	24.0	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	570	Cast Iron	UNC 5/8-13"
AMRE-C101026-20	19.69 (500mm)	10.000	10.000	25.5	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	1.50	3.000	425	Epoxy	UNC 1/2"-13
AMRE-C101028-20	19.69 (500mm)	10.000	10.000	27.5	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	1.50	3.000	450	Epoxy	UNC 1/2"-13
AMR-C101028-20	19.69 (500mm)	10.000	10.000	28.0	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	-	635	Cast Iron	Plain Face
AMR-C101028-20-50	19.69 (500mm)	10.000	10.000	28.0	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	635	Cast Iron	UNC 1/2"-13
AMR-C101028-20-62	19.69 (500mm)	10.000	10.000	28.0	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	635	Cast Iron	UNC 5/8-13"
AMRE-C101030-20	19.69 (500mm)	10.000	10.000	29.5	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	1.50	3.000	470	Epoxy	UNC 1/2"-13
AMRE-C101032-20	19.69 (500mm)	10.000	10.000	31.5	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	1.50	3.000	495	Epoxy	UNC 1/2"-13
AMR-C101032-20	19.69 (500mm)	10.000	10.000	32.0	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	-	715	Cast Iron	Plain Face
AMR-C101032-20-50	19.69 (500mm)	10.000	10.000	32.0	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	715	Cast Iron	UNC 1/2"-13
AMR-C101032-20-62	19.69 (500mm)	10.000	10.000	32.0	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	715	Cast Iron	UNC 5/8-13"
AMRE-C101034-20	19.69 (500mm)	10.000	10.000	33.5	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	1.50	3.000	515	Epoxy	UNC 1/2"-13
AMR-C101036-25	19.69 (500mm)	10.000	10.000	36.0	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	-	900	Cast Iron	Plain Face
AMR-C101036-25-50	19.69 (500mm)	10.000	10.000	36.0	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	900	Cast Iron	UNC 1/2"-13
AMR-C101036-25-62	19.69 (500mm)	10.000	10.000	36.0	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	900	Cast Iron	UNC 5/8-13"
AMR-C101430-20	19.69 (500mm)	10.000	14.000	30.0	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	-	805	Cast Iron	Plain Face
AMR-C101430-20-50	19.69 (500mm)	10.000	14.000	30.0	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	805	Cast Iron	UNC 1/2"-13
AMR-C101430-20-62	19.69 (500mm)	10.000	14.000	30.0	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	805	Cast Iron	UNC 5/8-13"
AMR-C121219-20	19.69 (500mm)	12.000	12.000	18.5	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	-	545	Cast Iron	Plain Face
AMR-C121219-20-50	19.69 (500mm)	12.000	12.000	18.5	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	545	Cast Iron	UNC 1/2"-13
AMR-C121219-20-62	19.69 (500mm)	12.000	12.000	18.5	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	545	Cast Iron	UNC 5/8-13"
AMRE-C121222-20	19.69 (500mm)	12.000	12.000	21.5	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	1.50	3.000	420	Epoxy	UNC 1/2"-13
AMR-C121222-20	19.69 (500mm)	12.000	12.000	22.0	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	-	620	Cast Iron	Plain Face
AMR-C121222-20-50	19.69 (500mm)	12.000	12.000	22.0	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	620	Cast Iron	UNC 1/2"-13
AMR-C121222-20-62	19.69 (500mm)	12.000	12.000	22.0	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	620	Cast Iron	UNC 5/8-13"
AMRE-C121224-20	19.69 (500mm)	12.000	12.000	23.5	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	1.50	3.000	445	Epoxy	UNC 1/2"-13
AMR-C121224-20	19.69 (500mm)	12.000	12.000	24.0	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	-	660	Cast Iron	Plain Face
AMR-C121224-20-50	19.69 (500mm)	12.000	12.000	24.0	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	660	Cast Iron	UNC 1/2"-13
AMR-C121224-20-62	19.69 (500mm)	12.000	12.000	24.0	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	660	Cast Iron	UNC 5/8-13"
AMRE-C121226-20	19.69 (500mm)	12.000	12.000	25.5	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	1.50	3.000	470	Epoxy	UNC 1/2"-13
AMRE-C121228-20	19.69 (500mm)	12.000	12.000	27.5	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	1.50	3.000	495	Epoxy	UNC 1/2"-13
AMR-C121228-20	19.69 (500mm)	12.000	12.000	28.0	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	-	745	Cast Iron	Plain Face
AMR-C121228-20-50	19.69 (500mm)	12.000	12.000	28.0	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	745	Cast Iron	UNC 1/2"-13
AMR-C121228-20-62	19.69 (500mm)	12.000	12.000	28.0	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	745	Cast Iron	UNC 5/8-13"
AMRE-C121230-20	19.69 (500mm)	12.000	12.000	29.5	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	1.50	3.000	515	Epoxy	UNC 1/2"-13
AMR-C121231-20	19.69 (500mm)	12.000	12.000	30.5	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	-	795	Cast Iron	Plain Face
AMR-C121231-20-50	19.69 (500mm)	12.000	12.000	30.5	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	795	Cast Iron	UNC 1/2"-13
AMR-C121231-20-62	19.69 (500mm)	12.000	12.000	30.5	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	795	Cast Iron	UNC 5/8-13"
AMRE-C121232-20	19.69 (500mm)	12.000	12.000	31.5	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	1.50	3.000	540	Epoxy	UNC 1/2"-13
AMR-C121232-20	19.69 (500mm)	12.000	12.000	32.0	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	-	860	Cast Iron	Plain Face
AMR-C121232-20-50	19.69 (500mm)	12.000	12.000	32.0	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	860	Cast Iron	UNC 1/2"-13
AMR-C121232-20-62	19.69 (500mm)	12.000	12.000	32.0	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	860	Cast Iron	UNC 5/8-13"
AMR-C121624-20	19.69 (500mm)	12.000	16.000	24.0	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	-	755	Cast Iron	Plain Face
AMR-C121624-20-50	19.69 (500mm)	12.000	16.000	24.0	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	755	Cast Iron	UNC 1/2"-13
AMR-C121624-20-62	19.69 (500mm)	12.000	16.000	24.0	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	755	Cast Iron	UNC 5/8-13"
AMR-C121628-20	19.69 (500mm)	12.000	16.000	28.0	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	-	855	Cast Iron	Plain Face
AMR-C121628-20-50	19.69 (500mm)	12.000	16.000	28.0	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	855	Cast Iron	UNC 1/2"-13
AMR-C121628-20-62	19.69 (500mm)	12.000	16.000	28.0	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	855	Cast Iron	UNC 5/8-13"
AMR-C121832-20	19.69 (500mm)	12.000	18.000	32.0	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	-	1050	Cast Iron	Plain Face
AMR-C121832-20-50	19.69 (500mm)	12.000	18.000	32.0	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	1050	Cast Iron	UNC 1/2"-13
AMR-C121832-20-62	19.69 (500mm)	12.000	18.000	32.0	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	1050	Cast Iron	UNC 5/8-13"
AMRE-C141428-20	19.69 (500mm)	14.000	14.000	27.5	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	1.50	3.000	585	Epoxy	UNC 1/2"-13
AMR-C141428-20	19.69 (500mm)	14.000	14.000	28.0	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	-	850	Cast Iron	Plain Face
AMR-C141428-20-50	19.69 (500mm)	14.000	14.000	28.0	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	850	Cast Iron	UNC 1/2"-13
AMR-C141428-20-62	19.69 (500mm)	14.000	14.000	28.0	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	2.00	3.000	850	Cast Iron	UNC 5/8-13"
AMRE-C141430-20	19.69 (500mm)	14.000	14.000	29.5	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	1.50	3.000	615	Epoxy	UNC 1/2"-13
AMRE-C141432-20	19.69 (500mm)	14.000	14.000	31.5	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	1.50	3.000	645	Epoxy	UNC 1/2"-13
AMRE-C141434-20	19.69 (500mm)	14.000	14.000	33.5	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	1.50	3.000	675	Epoxy	UNC 1/2"-13
AMRE-C161628-20	19.69 (500mm)	16.000	16.000	27.5	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	1.50	3.000	675	Epoxy	UNC 1/2"-13
AMRE-C161630-20	19.69 (500mm)	16.000	16.000	29.5	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	1.50	3.000	710	Epoxy	UNC 1/2"-13
AMRE-C161632-20	19.69 (500mm)	16.000	16.000	31.5	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	1.50	3.000	745	Epoxy	UNC 1/2"-13
AMRE-C161634-20	19.69 (500mm)	16.000	16.000	33.5	15.748 (400mm) to 16.000 (406.4mm)	5.906 (150mm)	1.50	3.000	780	Epoxy	UNC 1/2"-13
AMRE-C080820-25	24.80 (630mm)	8.000	8.000	19.5	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	1.50	3.000	400	Epoxy	UNC 1/2"-13
AMRE-C080822-25	24.80 (630mm)	8.000	8.000	21.5	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	1.50	3.000	415	Epoxy	UNC 1/2"-13
AMRE-C080824-25	24.80 (630mm)	8.000	8.000	23.5	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	1.50	3.000	430	Epoxy	UNC 1/2"-13
AMRE-C080826-25	24.80 (630mm)	8.000	8.000	25.5	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	1.50	3.000	445	Epoxy	UNC 1/2"-13
AMR-C081836-25	24.80 (630mm)	8.000	18.000	36.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	-	1145	Cast Iron	Plain Face
AMR-C081836-25-50	24.80 (630mm)	8.000	18.000	36.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	1145	Cast Iron	UNC 1/2"-13
AMR-C081836-25-62	24.80 (630mm)	8.000	18.000	36.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	1145	Cast Iron	UNC 5/8-13"
AMR-C101016-25	24.80 (630mm)	10.000	10.000	16.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	-	555	Cast Iron	Plain Face
AMR-C101016-25-50	24.80 (630mm)	10.000	10.000	16.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	555	Cast Iron	UNC 1/2"-13
AMR-C101016-25-62	24.80 (630mm)	10.000	10.000	16.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	555	Cast Iron	UNC 5/8-13"
AMR-C101024-25	24.80 (630mm)	10.000	10.000	24.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	-	685	Cast Iron	Plain Face
AMR-C101024-25-50	24.80 (630mm)	10.000	10.000	24.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	685	Cast Iron	UNC 1/2"-13
AMR-C101024-25-62	24.80 (630mm)	10.000	10.000	24.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	685	Cast Iron	UNC 5/8-13"
AMRE-C101026-25	24.80 (630mm)	10.000	10.000	25.5	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	1.50	3.000	520	Epoxy	UNC 1/2"-13
AMR-C101026-25	24.80 (630mm)	10.000	10.000	26.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	-	720	Cast Iron	Plain Face
AMR-C101026-25-50	24.80 (630mm)	10.000	10.000	26.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	720	Cast Iron	UNC 1/2"-13
AMR-C101026-25-62	24.80 (630mm)	10.000	10.000	26.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	720	Cast Iron	UNC 5/8-13"
AMRE-C101028-25	24.80 (630mm)	10.000	10.000	27.5	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	1.50	3.000	545	Epoxy	UNC 1/2"-13
AMR-C101028-25	24.80 (630mm)	10.000	10.000	28.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	-	755	Cast Iron	Plain Face
AMR-C101028-25-50	24.80 (630mm)	10.000	10.000	28.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	755	Cast Iron	UNC 1/2"-13
AMR-C101028-25-62	24.80 (630mm)	10.000	10.000	28.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	755	Cast Iron	UNC 5/8-13"
AMRE-C101030-25	24.80 (630mm)	10.000	10.000	29.5	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	1.50	3.000	565	Epoxy	UNC 1/2"-13
AMR-C101030-25	24.80 (630mm)	10.000	10.000	30.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	-	805	Cast Iron	Plain Face
AMR-C101030-25-50	24.80 (630mm)	10.000	10.000	30.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	805	Cast Iron	UNC 1/2"-13
AMR-C101030-25-62	24.80 (630mm)	10.000	10.000	30.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	805	Cast Iron	UNC 5/8-13"
AMRE-C101032-25	24.80 (630mm)	10.000	10.000	31.5	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	1.50	3.000	590	Epoxy	UNC 1/2"-13
AMR-C101032-25	24.80 (630mm)	10.000	10.000	32.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	-	820	Cast Iron	Plain Face
AMR-C101032-25-50	24.80 (630mm)	10.000	10.000	32.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	820	Cast Iron	UNC 1/2"-13
AMR-C101032-25-62	24.80 (630mm)	10.000	10.000	32.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	820	Cast Iron	UNC 5/8-13"
AMRE-C101034-25	24.80 (630mm)	10.000	10.000	33.5	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	1.50	3.000	610	Epoxy	UNC 1/2"-13
AMR-C101430-25	24.80 (630mm)	10.000	14.000	30.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	-	930	Cast Iron	Plain Face
AMR-C101430-25-50	24.80 (630mm)	10.000	14.000	30.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	930	Cast Iron	UNC 1/2"-13
AMR-C101430-25-62	24.80 (630mm)	10.000	14.000	30.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	930	Cast Iron	UNC 5/8-13"
AMRE-C121222-25	24.80 (630mm)	12.000	12.000	21.5	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	1.50	3.000	515	Epoxy	UNC 1/2"-13
AMRE-C121224-25	24.80 (630mm)	12.000	12.000	23.5	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	1.50	3.000	540	Epoxy	UNC 1/2"-13
AMR-C121224-25	24.80 (630mm)	12.000	12.000	24.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	-	780	Cast Iron	Plain Face
AMR-C121224-25-50	24.80 (630mm)	12.000	12.000	24.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	780	Cast Iron	UNC 1/2"-13
AMR-C121224-25-62	24.80 (630mm)	12.000	12.000	24.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	780	Cast Iron	UNC 5/8-13"
AMRE-C121226-25	24.80 (630mm)	12.000	12.000	25.5	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	1.50	3.000	565	Epoxy	UNC 1/2"-13
AMRE-C121228-25	24.80 (630mm)	12.000	12.000	27.5	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	1.50	3.000	590	Epoxy	UNC 1/2"-13
AMR-C121228-25	24.80 (630mm)	12.000	12.000	28.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	-	865	Cast Iron	Plain Face
AMR-C121228-25-50	24.80 (630mm)	12.000	12.000	28.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	865	Cast Iron	UNC 1/2"-13
AMR-C121228-25-62	24.80 (630mm)	12.000	12.000	28.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	865	Cast Iron	UNC 5/8-13"
AMRE-C121230-25	24.80 (630mm)	12.000	12.000	29.5	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	1.50	3.000	610	Epoxy	UNC 1/2"-13
AMR-C121230-25	24.80 (630mm)	12.000	12.000	30.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	-	905	Cast Iron	Plain Face
AMR-C121230-25-50	24.80 (630mm)	12.000	12.000	30.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	905	Cast Iron	UNC 1/2"-13
AMR-C121230-25-62	24.80 (630mm)	12.000	12.000	30.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	905	Cast Iron	UNC 5/8-13"
AMRE-C121232-25	24.80 (630mm)	12.000	12.000	31.5	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	1.50	3.000	635	Epoxy	UNC 1/2"-13
AMR-C121232-25	24.80 (630mm)	12.000	12.000	32.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	-	945	Cast Iron	Plain Face
AMR-C121232-25-50	24.80 (630mm)	12.000	12.000	32.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	945	Cast Iron	UNC 1/2"-13
AMR-C121232-25-62	24.80 (630mm)	12.000	12.000	32.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	945	Cast Iron	UNC 5/8-13"
AMR-C121236-25	24.80 (630mm)	12.000	12.000	36.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	-	1030	Cast Iron	Plain Face
AMR-C121236-25-50	24.80 (630mm)	12.000	12.000	36.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	1030	Cast Iron	UNC 1/2"-13
AMR-C121236-25-62	24.80 (630mm)	12.000	12.000	36.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	1030	Cast Iron	UNC 5/8-13"
AMR-C121624-25	24.80 (630mm)	12.000	16.000	24.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	-	870	Cast Iron	Plain Face
AMR-C121624-25-50	24.80 (630mm)	12.000	16.000	24.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	870	Cast Iron	UNC 1/2"-13
AMR-C121624-25-62	24.80 (630mm)	12.000	16.000	24.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	870	Cast Iron	UNC 5/8-13"
AMR-C121630-25	24.80 (630mm)	12.000	16.000	30.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	-	1020	Cast Iron	Plain Face
AMR-C121630-25-50	24.80 (630mm)	12.000	16.000	30.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	1020	Cast Iron	UNC 1/2"-13
AMR-C121630-25-62	24.80 (630mm)	12.000	16.000	30.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	1020	Cast Iron	UNC 5/8-13"
AMR-C121632-25	24.80 (630mm)	12.000	16.000	32.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	-	1070	Cast Iron	Plain Face
AMR-C121632-25-50	24.80 (630mm)	12.000	16.000	32.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	1070	Cast Iron	UNC 1/2"-13
AMR-C121632-25-62	24.80 (630mm)	12.000	16.000	32.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	1070	Cast Iron	UNC 5/8-13"
AMR-C121824-25	24.80 (630mm)	12.000	18.000	24.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	-	915	Cast Iron	Plain Face
AMR-C121824-25-50	24.80 (630mm)	12.000	18.000	24.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	915	Cast Iron	UNC 1/2"-13
AMR-C121824-25-62	24.80 (630mm)	12.000	18.000	24.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	915	Cast Iron	UNC 5/8-13"
AMR-C121828-25	24.80 (630mm)	12.000	18.000	28.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	-	1025	Cast Iron	Plain Face
AMR-C121828-25-50	24.80 (630mm)	12.000	18.000	28.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	1025	Cast Iron	UNC 1/2"-13
AMR-C121828-25-62	24.80 (630mm)	12.000	18.000	28.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	1025	Cast Iron	UNC 5/8-13"
AMR-C121830-25	24.80 (630mm)	12.000	18.000	30.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	-	1080	Cast Iron	Plain Face
AMR-C121830-25-50	24.80 (630mm)	12.000	18.000	30.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	1080	Cast Iron	UNC 1/2"-13
AMR-C121830-25-62	24.80 (630mm)	12.000	18.000	30.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	1080	Cast Iron	UNC 5/8-13"
AMR-C121832-25	24.80 (630mm)	12.000	18.000	32.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	-	1135	Cast Iron	Plain Face
AMR-C121832-25-50	24.80 (630mm)	12.000	18.000	32.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	1135	Cast Iron	UNC 1/2"-13
AMR-C121832-25-62	24.80 (630mm)	12.000	18.000	32.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	1135	Cast Iron	UNC 5/8-13"
AMR-C121836-25	24.80 (630mm)	12.000	18.000	36.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	-	1295	Cast Iron	Plain Face
AMR-C121836-25-50	24.80 (630mm)	12.000	18.000	36.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	1295	Cast Iron	UNC 1/2"-13
AMR-C121836-25-62	24.80 (630mm)	12.000	18.000	36.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	1295	Cast Iron	UNC 5/8-13"
AMR-C121842-25	24.80 (630mm)	12.000	18.000	42.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	-	1480	Cast Iron	Plain Face
AMR-C121842-25-50	24.80 (630mm)	12.000	18.000	42.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	1480	Cast Iron	UNC 1/2"-13
AMR-C121842-25-62	24.80 (630mm)	12.000	18.000	42.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	1480	Cast Iron	UNC 5/8-13"
AMR-C141424-25	24.80 (630mm)	14.000	14.000	24.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	-	870	Cast Iron	Plain Face
AMR-C141424-25-50	24.80 (630mm)	14.000	14.000	24.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	870	Cast Iron	UNC 1/2"-13
AMR-C141424-25-62	24.80 (630mm)	14.000	14.000	24.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	870	Cast Iron	UNC 5/8-13"
AMRE-C141428-25	24.80 (630mm)	14.000	14.000	27.5	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	1.50	3.000	680	Epoxy	UNC 1/2"-13
AMR-C141428-25	24.80 (630mm)	14.000	14.000	28.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	-	1000	Cast Iron	Plain Face
AMR-C141428-25-50	24.80 (630mm)	14.000	14.000	28.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	1000	Cast Iron	UNC 1/2"-13
AMR-C141428-25-62	24.80 (630mm)	14.000	14.000	28.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	1000	Cast Iron	UNC 5/8-13"
AMRE-C141430-25	24.80 (630mm)	14.000	14.000	29.5	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	1.50	3.000	710	Epoxy	UNC 1/2"-13
AMR-C141430-25	24.80 (630mm)	14.000	14.000	30.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	-	1020	Cast Iron	Plain Face
AMR-C141430-25-50	24.80 (630mm)	14.000	14.000	30.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	1020	Cast Iron	UNC 1/2"-13
AMR-C141430-25-62	24.80 (630mm)	14.000	14.000	30.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	1020	Cast Iron	UNC 5/8-13"
AMRE-C141432-25	24.80 (630mm)	14.000	14.000	31.5	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	1.50	3.000	740	Epoxy	UNC 1/2"-13
AMR-C141432-25	24.80 (630mm)	14.000	14.000	32.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	-	1110	Cast Iron	Plain Face
AMR-C141432-25-50	24.80 (630mm)	14.000	14.000	32.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	1110	Cast Iron	UNC 1/2"-13
AMR-C141432-25-62	24.80 (630mm)	14.000	14.000	32.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	1110	Cast Iron	UNC 5/8-13"
AMRE-C141434-25	24.80 (630mm)	14.000	14.000	33.5	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	1.50	3.000	770	Epoxy	UNC 1/2"-13
AMRE-C141436-25	24.80 (630mm)	14.000	14.000	35.5	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	1.50	3.000	795	Epoxy	UNC 1/2"-13
AMR-C141436-25	24.80 (630mm)	14.000	14.000	36.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	-	1205	Cast Iron	Plain Face
AMR-C141436-25-50	24.80 (630mm)	14.000	14.000	36.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	1205	Cast Iron	UNC 1/2"-13
AMR-C141436-25-62	24.80 (630mm)	14.000	14.000	36.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	1205	Cast Iron	UNC 5/8-13"
AMRE-C141438-25	24.80 (630mm)	14.000	14.000	37.5	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	1.50	3.000	830	Epoxy	UNC 1/2"-13
AMRE-C141440-25	24.80 (630mm)	14.000	14.000	39.5	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	1.50	3.000	855	Epoxy	UNC 1/2"-13
AMR-C161624-25	24.80 (630mm)	16.000	16.000	24.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	-	965	Cast Iron	Plain Face
AMR-C161624-25-50	24.80 (630mm)	16.000	16.000	24.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	965	Cast Iron	UNC 1/2"-13
AMR-C161624-25-62	24.80 (630mm)	16.000	16.000	24.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	965	Cast Iron	UNC 5/8-13"
AMRE-C161628-25	24.80 (630mm)	16.000	16.000	27.5	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	1.50	3.000	770	Epoxy	UNC 1/2"-13
AMR-C161628-25	24.80 (630mm)	16.000	16.000	28.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	-	1080	Cast Iron	Plain Face
AMR-C161628-25-50	24.80 (630mm)	16.000	16.000	28.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	1080	Cast Iron	UNC 1/2"-13
AMR-C161628-25-62	24.80 (630mm)	16.000	16.000	28.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	1080	Cast Iron	UNC 5/8-13"
AMRE-C161630-25	24.80 (630mm)	16.000	16.000	29.5	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	1.50	3.000	805	Epoxy	UNC 1/2"-13
AMR-C161630-25	24.80 (630mm)	16.000	16.000	30.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	-	1135	Cast Iron	Plain Face
AMR-C161630-25-50	24.80 (630mm)	16.000	16.000	30.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	1135	Cast Iron	UNC 1/2"-13
AMR-C161630-25-62	24.80 (630mm)	16.000	16.000	30.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	1135	Cast Iron	UNC 5/8-13"
AMRE-C161632-25	24.80 (630mm)	16.000	16.000	31.5	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	1.50	3.000	840	Epoxy	UNC 1/2"-13
AMR-C161632-25	24.80 (630mm)	16.000	16.000	32.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	-	1240	Cast Iron	Plain Face
AMR-C161632-25-50	24.80 (630mm)	16.000	16.000	32.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	1240	Cast Iron	UNC 1/2"-13
AMR-C161632-25-62	24.80 (630mm)	16.000	16.000	32.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	1240	Cast Iron	UNC 5/8-13"
AMRE-C161634-25	24.80 (630mm)	16.000	16.000	33.5	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	1.50	3.000	875	Epoxy	UNC 1/2"-13
AMRE-C161636-25	24.80 (630mm)	16.000	16.000	33.5	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	1.50	3.000	910	Epoxy	UNC 1/2"-13
AMR-C161636-25	24.80 (630mm)	16.000	16.000	36.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	-	1360	Cast Iron	Plain Face
AMR-C161636-25-50	24.80 (630mm)	16.000	16.000	36.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	1360	Cast Iron	UNC 1/2"-13
AMR-C161636-25-62	24.80 (630mm)	16.000	16.000	36.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	1360	Cast Iron	UNC 5/8-13"
AMRE-C161638-25	24.80 (630mm)	16.000	16.000	37.5	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	1.50	3.000	945	Epoxy	UNC 1/2"-13
AMRE-C161640-25	24.80 (630mm)	16.000	16.000	39.5	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	1.50	3.000	980	Epoxy	UNC 1/2"-13
AMR-C181824-25	24.80 (630mm)	18.000	18.000	24.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	-	1055	Cast Iron	Plain Face
AMR-C181824-25-50	24.80 (630mm)	18.000	18.000	24.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	1055	Cast Iron	UNC 1/2"-13
AMR-C181824-25-62	24.80 (630mm)	18.000	18.000	24.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	1055	Cast Iron	UNC 5/8-13"
AMR-C181830-25	24.80 (630mm)	18.000	18.000	30.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	-	1255	Cast Iron	Plain Face
AMR-C181830-25-50	24.80 (630mm)	18.000	18.000	30.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	1255	Cast Iron	UNC 1/2"-13
AMR-C181830-25-62	24.80 (630mm)	18.000	18.000	30.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	1255	Cast Iron	UNC 5/8-13"
AMR-C181832-25	24.80 (630mm)	18.000	18.000	32.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	-	1320	Cast Iron	Plain Face
AMR-C181832-25-50	24.80 (630mm)	18.000	18.000	32.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	1320	Cast Iron	UNC 1/2"-13
AMR-C181832-25-62	24.80 (630mm)	18.000	18.000	32.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	1320	Cast Iron	UNC 5/8-13"
AMR-C181838-25	24.80 (630mm)	18.000	18.000	38.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	-	1496	Cast Iron	Plain Face
AMR-C181838-25-50	24.80 (630mm)	18.000	18.000	38.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	1496	Cast Iron	UNC 1/2"-13
AMR-C181838-25-62	24.80 (630mm)	18.000	18.000	38.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	1496	Cast Iron	UNC 5/8-13"
AMR-C202024-25	24.80 (630mm)	20.000	20.000	24.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	-	1145	Cast Iron	Plain Face
AMR-C202024-25-50	24.80 (630mm)	20.000	20.000	24.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	1145	Cast Iron	UNC 1/2"-13
AMR-C202024-25-62	24.80 (630mm)	20.000	20.000	24.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	1145	Cast Iron	UNC 5/8-13"
AMR-C202030-25	24.80 (630mm)	20.000	20.000	30.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	-	1370	Cast Iron	Plain Face
AMR-C202030-25-50	24.80 (630mm)	20.000	20.000	30.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	1370	Cast Iron	UNC 1/2"-13
AMR-C202030-25-62	24.80 (630mm)	20.000	20.000	30.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	1370	Cast Iron	UNC 5/8-13"
AMR-C202032-25	24.80 (630mm)	20.000	20.000	32.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	-	1445	Cast Iron	Plain Face
AMR-C202032-25-50	24.80 (630mm)	20.000	20.000	32.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	1445	Cast Iron	UNC 1/2"-13
AMR-C202032-25-62	24.80 (630mm)	20.000	20.000	32.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	1445	Cast Iron	UNC 5/8-13"
AMR-C202036-25	24.80 (630mm)	20.000	20.000	36.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	-	1675	Cast Iron	Plain Face
AMR-C202036-25-50	24.80 (630mm)	20.000	20.000	36.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	1675	Cast Iron	UNC 1/2"-13
AMR-C202036-25-62	24.80 (630mm)	20.000	20.000	36.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	1675	Cast Iron	UNC 5/8-13"
AMR-C222236-25	24.80 (630mm)	22.000	22.000	36.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	-	1830	Cast Iron	Plain Face
AMR-C222236-25-50	24.80 (630mm)	22.000	22.000	36.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	1830	Cast Iron	UNC 1/2"-13
AMR-C222236-25-62	24.80 (630mm)	22.000	22.000	36.0	19.685 (500mm) to 20.000 (508mm)	7.874 (200mm)	2.00	3.000	1830	Cast Iron	UNC 5/8-13"
AMRE-C121222-32	31.50 (800mm)	12.000	12.000	21.5	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	1.50	3.000	670	Epoxy	UNC 1/2"-13
AMRE-C121224-32	31.50 (800mm)	12.000	12.000	23.5	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	1.50	3.000	695	Epoxy	UNC 1/2"-13
AMRE-C121226-32	31.50 (800mm)	12.000	12.000	25.5	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	1.50	3.000	720	Epoxy	UNC 1/2"-13
AMRE-C121225-32	31.50 (800mm)	12.000	12.000	27.5	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	1.50	3.000	745	Epoxy	UNC 1/2"-13
AMRE-C121230-32	31.50 (800mm)	12.000	12.000	29.5	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	1.50	3.000	765	Epoxy	UNC 1/2"-13
AMRE-C121232-32	31.50 (800mm)	12.000	12.000	31.5	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	1.50	3.000	790	Epoxy	UNC 1/2"-13
AMR-C121232-32	31.50 (800mm)	12.000	12.000	32.0	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	2.00	-	1075	Cast Iron	Plain Face
AMR-C121232-32-50	31.50 (800mm)	12.000	12.000	32.0	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	2.00	3.000	1075	Cast Iron	UNC 1/2"-13
AMR-C121232-32-62	31.50 (800mm)	12.000	12.000	32.0	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	2.00	3.000	1075	Cast Iron	UNC 5/8-13"
AMR-C121836-32	31.50 (800mm)	12.000	18.000	36.0	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	2.00	-	1460	Cast Iron	Plain Face
AMR-C121836-32-50	31.50 (800mm)	12.000	18.000	36.0	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	2.00	3.000	1460	Cast Iron	UNC 1/2"-13
AMR-C121836-32-62	31.50 (800mm)	12.000	18.000	36.0	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	2.00	3.000	1460	Cast Iron	UNC 5/8-13"
AMRE-C141428-32	31.50 (800mm)	14.000	14.000	27.5	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	1.50	3.000	835	Epoxy	UNC 1/2"-13
AMRE-C141430-32	31.50 (800mm)	14.000	14.000	29.5	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	1.50	3.000	865	Epoxy	UNC 1/2"-13
AMRE-C141432-32	31.50 (800mm)	14.000	14.000	31.5	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	1.50	3.000	895	Epoxy	UNC 1/2"-13
AMRE-C141434-32	31.50 (800mm)	14.000	14.000	33.5	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	1.50	3.000	925	Epoxy	UNC 1/2"-13
AMRE-C141436-32	31.50 (800mm)	14.000	14.000	35.5	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	1.50	3.000	950	Epoxy	UNC 1/2"-13
AMRE-C141438-32	31.50 (800mm)	14.000	14.000	37.5	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	1.50	3.000	985	Epoxy	UNC 1/2"-13
AMRE-C141440-32	31.50 (800mm)	14.000	14.000	39.5	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	1.50	3.000	1010	Epoxy	UNC 1/2"-13
AMR-C142034-32	31.50 (800mm)	14.000	20.000	34.0	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	2.00	-	1565	Cast Iron	Plain Face
AMR-C142034-32-50	31.50 (800mm)	14.000	20.000	34.0	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	2.00	3.000	1565	Cast Iron	UNC 1/2"-13
AMR-C142034-32-62	31.50 (800mm)	14.000	20.000	34.0	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	2.00	3.000	1565	Cast Iron	UNC 5/8-13"
AMRE-C161628-32	31.50 (800mm)	16.000	16.000	27.5	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	1.50	3.000	925	Epoxy	UNC 1/2"-13
AMRE-C161630-32	31.50 (800mm)	16.000	16.000	29.5	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	1.50	3.000	960	Epoxy	UNC 1/2"-13
AMRE-C161632-32	31.50 (800mm)	16.000	16.000	31.5	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	1.50	3.000	995	Epoxy	UNC 1/2"-13
AMRE-C161634-32	31.50 (800mm)	16.000	16.000	33.5	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	1.50	3.000	1030	Epoxy	UNC 1/2"-13
AMRE-C161636-32	31.50 (800mm)	16.000	16.000	33.5	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	1.50	3.000	1065	Epoxy	UNC 1/2"-13
AMRE-C161638-32	31.50 (800mm)	16.000	16.000	37.5	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	1.50	3.000	1100	Epoxy	UNC 1/2"-13
AMRE-C161640-32	31.50 (800mm)	16.000	16.000	39.5	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	1.50	3.000	1135	Epoxy	UNC 1/2"-13
AMR-C252540-32	31.50 (800mm)	25.000	25.000	40.0	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	2.00	-	3365	Cast Iron	Plain Face
AMR-C252540-32-50	31.50 (800mm)	25.000	25.000	40.0	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	2.00	3.000	3365	Cast Iron	UNC 1/2"-13
AMR-C252540-32-62	31.50 (800mm)	25.000	25.000	40.0	25.000 (635mm) to 25.197 (640mm)	10.630 (270mm)	2.00	3.000	3365	Cast Iron	UNC 5/8-13"

0 models selected

Your Selection

Each model below is routed to the best next step based on availability.

Calculadora del tiempo de preparación

¿Cuánto cuesta el tiempo de configuración? ¿Te está saliendo caro?

Cada cambio implica tiempo de inactividad del husillo. Los sistemas de sujeción multipieza reducen drásticamente la frecuencia de los ajustes, por lo que tus máquinas pasan más horas cortando y menos tiempo esperando.

Tus máquinas

Máquinas CNC

Valor de la máquina por hora

El problema de la configuración

Cambios / Día / Máquina

Promedio de minutos por cambio

min

Establecer el objetivo de reducción

Costo anual de los cambios de decorado

1,500 hrs

Horas de funcionamiento del torno perdidas por la configuración / Año

$263K

Valor anual de la producción perdida

$131K

Recuperable con sujeción de piezas

Ver desglose completo del ROI

Based on 250 working days/yr. Multi-part fixturing reduces changeover frequency so your spindle spends more time cutting.

Desde el Centro de recursos

Contenido relacionado

Tombstone CNC de AMROK con sistema de sujeción SCHUNK VERO-S

1 min 51 sec

Videos Workholding Product Selection

Tombstone CNC de AMROK con sistema de sujeción SCHUNK VERO-S

Al combinar los productos de sujeción de AMROK y Schunk, una placa de sujeción CNC de AMROK mecanizada especialmente puede alojar los soportes de fijación de punto cero Vero-S de Schunk. Con un diseño autoblocante accionado por resorte y una instalación de pasadores en un ángulo de hasta 23 grados, los soportes Vero-S son capaces de reducir el tiempo de configuración en casi un 90 %.

Ver todos los recursos

Entrega de palés de WorkFlow

Slytek Software

AMROK Select

Tu pieza → Nuestro diseño → Mobiliario llave en mano

VariFlow

Serie MistFlow

El software de monitoreo CNC mejora el tiempo de actividad con los recursos existentes

Hennig entra en la lista INC5000 de 2025 en un momento en que el sector manufacturero estadounidense vuelve a apostar por la fiabilidad

Cubiertas para la caja de las camionetas de trabajo: la próxima mejora imprescindible para tu flota

Cubiertas de foso de seguridad

Puertas enrollables para camiones de trabajo

Cajas para generadores y soluciones de protección eléctrica

Cierre hidráulico de varilla RCHX

Fabricación por encargo

El software de monitoreo CNC mejora el tiempo de actividad con los recursos existentes

Hennig entra en la lista INC5000 de 2025 en un momento en que el sector manufacturero estadounidense vuelve a apostar por la fiabilidad

Cubiertas para la caja de las camionetas de trabajo: la próxima mejora imprescindible para tu flota

Aeroespacial y defensa

Automatización del mecanizado

Máquina herramienta CNC

Prensado y estampado

Vehículos de motor y vehículos utilitarios

Acerías y producción metalúrgica

Lápida cúbica

La calidad se basa en la precisión

¿Conocía nuestras placas de epóxi mineral?

Especificaciones técnicas

Your Selection

¿Cuánto cuesta el tiempo de configuración? ¿Te está saliendo caro?

Contenido relacionado

Tombstone CNC de AMROK con sistema de sujeción SCHUNK VERO-S
