Spieth AL/IL clamping sleeves utilize hydraulic tensioning to achieve superior concentricity in high-precision shaft-hub connections.
SPIETH Clamping Sleeves eliminate the need for expensive machining operations such as shaft and hub keyways, splines, shoulders and bolt holes by creating an instant "shrink-fit" connection.
| Product ID | 3D CAD | ød₁ (mm) [h6] | ød₂ (mm) [h5] | L Dia Mm | Clamping Initiation (Fₘₐₓ¹) (N) | Clamping Initiation (Cₘᵢₙ²) (mm) | Transmittable Force (M) (Nm) | Transmittable Force (Fₐ) (N) | |
|---|---|---|---|---|---|---|---|---|---|
| AL 10.15 | 10 | 15 | 19 | 11000 | 0.6 | 21 | 4200 | ||
| AL 100.130 | 100 | 130 | 62 | 106500 | 2 | 4685 | 93700 | ||
| AL 110.140 | 110 | 140 | 62 | 115700 | 2.1 | 5599 | 101800 | ||
| AL 12.18 | 12 | 18 | 19 | 11800 | 0.7 | 35 | 5900 | ||
| AL 120.150 | 120 | 150 | 62 | 125000 | 2.1 | 6672 | 111200 | ||
| AL 125.155 | 125 | 155 | 62 | 129600 | 2.1 | 7206 | 115300 | ||
| AL 130.160 | 130 | 160 | 62 | 134300 | 2.2 | 7767 | 119500 | ||
| AL 14.20 | 14 | 20 | 19 | 13400 | 0.8 | 49 | 6970 | ||
| AL 140.170 | 140 | 170 | 62 | 143500 | 2.2 | 9037 | 129100 | ||
| AL 15.22 | 15 | 22 | 19 | 13700 | 0.8 | 54 | 7260 | ||
| AL 150.180 | 150 | 180 | 62 | 152800 | 2.2 | 10314 | 137520 | ||
| AL 16.22 | 16 | 22 | 19 | 14900 | 0.8 | 64 | 8050 | ||
| AL 18.25 | 18 | 25 | 19 | 15900 | 0.9 | 80 | 8900 | ||
| AL 20.32 | 20 | 32 | 26 | 20600 | 0.9 | 124 | 12360 | ||
| AL 22.35 | 22 | 35 | 26 | 21700 | 0.9 | 143 | 13020 | ||
| AL 25.37 | 25 | 37 | 26 | 24500 | 1.1 | 190 | 15190 | ||
| AL 28.40 | 28 | 40 | 26 | 26900 | 1.1 | 237 | 16950 | ||
| AL 30.42 | 30 | 42 | 26 | 28300 | 1.1 | 272 | 18110 | ||
| AL 32.48 | 32 | 48 | 35 | 32400 | 1.2 | 389 | 24300 | ||
| AL 35.52 | 35 | 52 | 35 | 34400 | 1.2 | 457 | 26140 | ||
| AL 40.56 | 40 | 56 | 35 | 38900 | 1.2 | 599 | 29950 | ||
| AL 45.68 | 45 | 68 | 42 | 44700 | 1.2 | 804 | 35760 | ||
| AL 50.72 | 50 | 72 | 42 | 49400 | 1.2 | 988 | 39520 | ||
| AL 55.80 | 55 | 80 | 52 | 59000 | 1.5 | 1314 | 47790 | ||
| AL 60.85 | 60 | 85 | 52 | 63300 | 1.5 | 1557 | 51910 | ||
| AL 63.88 | 63 | 88 | 52 | 66000 | 1.5 | 1725 | 54780 | ||
| AL 65.90 | 65 | 90 | 52 | 67700 | 1.5 | 1848 | 56870 | ||
| AL 70.100 | 70 | 100 | 62 | 78800 | 1.5 | 2372 | 67770 | ||
| AL 75.105 | 75 | 105 | 62 | 83400 | 1.5 | 2690 | 71720 | ||
| AL 8.12 | 8 | 12 | 19 | 10000 | 0.5 | 12 | 3000 | ||
| AL 80.110 | 80 | 110 | 62 | 88100 | 1.6 | 3065 | 76650 | ||
| AL 85.115 | 85 | 115 | 62 | 92700 | 1.6 | 3427 | 80650 | ||
| AL 90.120 | 90 | 120 | 62 | 97200 | 1.6 | 3802 | 84500 | ||
| AL 95.125 | 95 | 125 | 62 | 101800 | 1.8 | 4251 | 89500 | ||
| IL 10.15 | 10 | 15 | 19 | 11000 | 0.6 | 21 | 4200 | ||
| IL 100.130 | 100 | 130 | 62 | 106500 | 2 | 4685 | 93700 | ||
| IL 110.140 | 110 | 140 | 62 | 115700 | 2.1 | 5599 | 101800 | ||
| IL 12.18 | 12 | 18 | 19 | 11800 | 0.7 | 35 | 5900 | ||
| IL 120.150 | 120 | 150 | 62 | 125000 | 2.1 | 6672 | 111200 | ||
| IL 125.155 | 125 | 155 | 62 | 129600 | 2.1 | 7206 | 115300 | ||
| IL 130.160 | 130 | 160 | 62 | 134300 | 2.2 | 7767 | 119500 | ||
| IL 14.20 | 14 | 20 | 19 | 13400 | 0.8 | 49 | 6970 | ||
| IL 140.170 | 140 | 170 | 62 | 143500 | 2.2 | 9037 | 129100 | ||
| IL 15.22 | 15 | 22 | 19 | 13700 | 0.8 | 54 | 7260 | ||
| IL 150.180 | 150 | 180 | 62 | 152800 | 2.2 | 10314 | 137520 | ||
| IL 16.22 | 16 | 22 | 19 | 14900 | 0.8 | 64 | 8050 | ||
| IL 18.25 | 18 | 25 | 19 | 15900 | 0.9 | 80 | 8900 | ||
| IL 20.32 | 20 | 32 | 26 | 20600 | 0.9 | 124 | 12360 | ||
| IL 22.35 | 22 | 35 | 26 | 21700 | 0.9 | 143 | 13020 | ||
| IL 25.37 | 25 | 37 | 26 | 24500 | 1.1 | 190 | 15190 | ||
| IL 28.40 | 28 | 40 | 26 | 26900 | 1.1 | 237 | 16950 | ||
| IL 30.42 | 30 | 42 | 26 | 28300 | 1.1 | 272 | 18110 | ||
| IL 32.48 | 32 | 48 | 35 | 32400 | 1.2 | 389 | 24300 | ||
| IL 35.52 | 35 | 52 | 35 | 34400 | 1.2 | 457 | 26140 | ||
| IL 40.56 | 40 | 56 | 35 | 38900 | 1.2 | 599 | 29950 | ||
| IL 45.68 | 45 | 68 | 42 | 44700 | 1.2 | 804 | 35760 | ||
| IL 50.72 | 50 | 72 | 42 | 49400 | 1.2 | 988 | 39520 | ||
| IL 55.80 | 55 | 80 | 52 | 59000 | 1.5 | 1314 | 47790 | ||
| IL 60.85 | 60 | 85 | 52 | 63300 | 1.5 | 1557 | 51910 | ||
| IL 63.88 | 63 | 88 | 52 | 66000 | 1.5 | 1725 | 54780 | ||
| IL 65.90 | 65 | 90 | 52 | 67700 | 1.5 | 1848 | 56870 | ||
| IL 70.100 | 70 | 100 | 62 | 78800 | 1.5 | 2372 | 67770 | ||
| IL 75.105 | 75 | 105 | 62 | 83400 | 1.5 | 2690 | 71720 | ||
| IL 8.12 | 8 | 12 | 19 | 10000 | 0.5 | 12 | 3000 | ||
| IL 80.110 | 80 | 110 | 62 | 88100 | 1.6 | 3065 | 76650 | ||
| IL 85.115 | 85 | 115 | 62 | 92700 | 1.6 | 3427 | 80650 | ||
| IL 90.120 | 90 | 120 | 62 | 97200 | 1.6 | 3802 | 84500 | ||
| IL 95.125 | 95 | 125 | 62 | 101800 | 1.8 | 4251 | 89500 |
