Easily adapts fixtures with smaller footprints to machines with larger pallets.
Features
Designed to fit most standardized machine pallets and fixtures.
400mm fixture > 500mm machine pallet
500mm fixture > 630mm machine pallet
630mm fixture > 800mm machine pallet
The Magyver plate can be located with edge pads or with the 50mm center bushing.
Uses standardized mounting holes for use on both metric and imperial machine pallets (1/2”, 5/8”, M12, or M16 mounting holes).
T-slots allow fastening to almost any mounting hole pattern (inch or metric) on various fixtures, tombstones, or sub plates.
Standard versions step down one machine size, ie 500mm pallet >400mm fixture. Optional edge locators allow for stepping down multiple machine sizes, ie 630mm>400mm.
Comes with standard 5/8”-11 and M16 T-Nuts for 18mm T-Slots (standard T-Nuts also available in 1/2”-13 and M12).
Center hole cover allows operators to blow chips out through the T-slots without interfering with the center locating bushing.
Need to mount a 400mm fixture onto a 500mm machine.
Options:
Make a special adapter plate
Modify the fixture or machine pallet
Solution: Magyver plate!
Magyver Plate
Technical Specifications
Showing 3 of 3 models
Loading...
Product ID
3D CAD
Buy Online
Fits Machine Pallet Size (mm)
Fits Base Sizes (mm)
A
B
C*
D**
E
F
G
Weight (lbs)
AMR-P2020-03-A16
500
< 400
9.84 in (250 mm)
2.36 in (60 mm)
15.75 in (400 mm)
7.875 in (200 mm) to 8.000
2.17 in (55 mm)
2.95 in (75 mm)
8.25 in
220 lbs (100 kg)
AMR-P2525-03-A20
630
< 500
12.40 in (315 mm)
2.76 in (70 mm)
19.69 in (500 mm)
9.843 in (250 mm) to 10.000
2.95 in (75 mm)
3.94 in (100 mm)
11.50 in
400 lbs (182 kg)
AMR-P3232-03-A25
800
< 630
15.75 in (400 mm)
3.94 in (100 mm)
24.80 in (630 mm)
12.500 in to 12.598 in (320 mm)
3.94 in (100 mm)
5.32 in (135 mm)
12.50 in
650 lbs (295 kg)
Scroll
0 models selected
Your Selection
Each model below is routed to the best next step based on availability.
Buy Online NowShopify
Request a QuoteNot sold online
Quick access — enter your info to download STEP files
Preparing files...
Send a quote request — our engineers respond within one business day
✓ Quote request sent! Our team will follow up within one business day.
Magyver Plate
Adapter Extension/Spacer Dimensions
Showing 16 of 16 models
Loading...
Product ID
3D CAD
Buy Online
Adapts from (mm)
Adapts to (mm)
A
B
AMF-20A16S
500 mm
400 mm
4.75 in
0.98 in (25 mm)
AMF-20A16L
500 mm
400 mm
8.25 in
0.98 in (25 mm)
AMF-20A12S
500 mm
300 mm
4.75 in
2.95 in (75 mm)
AMF-20A12L
500 mm
300 mm
8.25 in
2.95 in (75 mm)
AMF-25A20S
630 mm
500 mm
4.75 in
1.57 in (40 mm)
AMF-25A20L
630 mm
500 mm
11.50 in
1.57 in (40 mm)
AMF-25A16S
630 mm
400 mm
4.75 in
3.54 in (90 mm)
AMF-25A16L
630 mm
400 mm
11.50 in
3.54 in (90 mm)
AMF-25A12S
630 mm
300 mm
4.75 in
5.51 in (140 mm)
AMF-25A12L
630 mm
300 mm
11.50 in
5.51 in (140 mm)
AMF-32A25S
800 mm
630 mm
4.75 in
2.36 in (60 mm)
AMF-32A25L
800 mm
630 mm
12.50 in
2.36 in (60 mm)
AMF-32A20S
800 mm
500 mm
4.75 in
4.92 in (125 mm)
AMF-32A20L
800 mm
500 mm
12.50 in
4.92 in (125 mm)
AMF-32A16S
800 mm
400 mm
4.75 in
6.89 in (175 mm)
AMF-32A16L
800 mm
400 mm
12.50 in
6.89 in (175 mm)
