Delivering high-precision linear guidance with adjustable play, the FDK/FDL series ensures smooth operation and easy assembly, even in dynamic and high-power-density applications.
SPIETH Adjustable Hydrodynamic Guide Bushings offer accurate guiding, adjustable guide clearance, and a hydrodynamic lubrication effect.
| Product ID | 3D CAD | ød₁ (mm) [h6₁] | ød₂ (mm) [h5] | K or L (mm) | ød₃ (mm) [h7] | øL1 (mm) | øL2 (mm) | øL3 (mm) | øL4 (mm) | ød₄ max (mm) | Perm. Radial Stress Fr (N) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| FDK 20.37 | 20 | 37 | 30 | 3 | 2.5 | 15 | 15.0 | 16 | 6 | 1800 | ||
| FDL 20.37 | 20 | 37 | 46 | 3 | 2.5 | 15 | 15.0 | 16 | 6 | 3600 | ||
| FDK 25.42 | 25 | 42 | 30 | 3 | 2.5 | 15 | 15.0 | 16 | 6 | 2260 | ||
| FDL 25.42 | 25 | 42 | 46 | 3 | 2.5 | 15 | 15.0 | 16 | 6 | 4500 | ||
| FDK 30.47 | 30 | 47 | 30 | 3 | 2.5 | 15 | 15.0 | 16 | 6 | 2810 | ||
| FDL 30.47 | 30 | 47 | 46 | 3 | 2.5 | 15 | 15.0 | 16 | 6 | 5720 | ||
| FDK 35.55 | 35 | 55 | 42 | 4 | 3.5 | 21 | 20.0 | 22 | 10 | 5290 | ||
| FDL 35.55 | 35 | 55 | 62 | 4 | 3.5 | 21 | 20.0 | 22 | 10 | 9070 | ||
| FDK 40.62 | 40 | 62 | 42 | 4 | 3.5 | 21 | 20.0 | 22 | 10 | 6050 | ||
| FDL 40.62 | 40 | 62 | 62 | 4 | 3.5 | 21 | 20.0 | 22 | 10 | 10370 | ||
| FDK 45.68 | 45 | 68 | 42 | 4 | 3.5 | 21 | 20.0 | 22 | 10 | 6800 | ||
| FDL 45.68 | 45 | 68 | 62 | 4 | 3.5 | 21 | 20.0 | 22 | 10 | 11660 | ||
| FDK 50.72 | 50 | 72 | 42 | 4 | 3.5 | 21 | 20.0 | 22 | 10 | 7560 | ||
| FDL 50.72 | 50 | 72 | 62 | 4 | 3.5 | 21 | 20.0 | 22 | 10 | 12960 | ||
| FDK 55.80 | 55 | 80 | 42 | 4 | 3.5 | 21 | 21.5 | 25 | 12 | 8320 | ||
| FDL 55.80 | 55 | 80 | 68 | 4 | 3.5 | 21 | 21.5 | 25 | 12 | 16630 | ||
| FDK 60.85 | 60 | 85 | 42 | 4 | 3.5 | 21 | 21.5 | 25 | 12 | 9070 | ||
| FDL 60.85 | 60 | 85 | 68 | 4 | 3.5 | 21 | 21.5 | 25 | 12 | 18140 | ||
| FDK 65.90 | 65 | 90 | 42 | 4 | 3.5 | 21 | 21.5 | 25 | 12 | 9830 | ||
| FDL 65.90 | 65 | 90 | 68 | 4 | 3.5 | 21 | 21.5 | 25 | 12 | 19660 | ||
| FDK 70.100 | 70 | 100 | 48 | 4 | 3.5 | 24 | 24.0 | 30 | 14 | 12100 | ||
| FDL 70.100 | 70 | 100 | 78 | 4 | 3.5 | 24 | 24.0 | 30 | 14 | 25200 | ||
| FDK 75.105 | 75 | 105 | 48 | 4 | 3.5 | 24 | 24.0 | 30 | 14 | 12960 | ||
| FDL 75.105 | 75 | 105 | 78 | 4 | 3.5 | 24 | 24.0 | 30 | 14 | 27000 | ||
| FDK 80.110 | 80 | 110 | 48 | 4 | 3.5 | 24 | 24.0 | 30 | 14 | 13820 | ||
| FDL 80.110 | 80 | 110 | 78 | 4 | 3.5 | 24 | 24.0 | 30 | 14 | 28800 | ||
| FDK 85.120 | 85 | 120 | 60 | 5 | 4.5 | 30 | 28.5 | 35 | 16 | 20810 | ||
| FDL 85.120 | 85 | 120 | 92 | 5 | 4.5 | 30 | 28.5 | 35 | 16 | 36110 | ||
| FDK 90.125 | 90 | 125 | 60 | 5 | 4.5 | 30 | 28.5 | 35 | 16 | 22030 | ||
| FDL 90.125 | 90 | 125 | 92 | 5 | 4.5 | 30 | 28.5 | 35 | 16 | 38230 | ||
| FDK 95.130 | 95 | 130 | 60 | 5 | 4.5 | 30 | 28.5 | 35 | 16 | 23260 | ||
| FDL 95.130 | 95 | 130 | 92 | 5 | 4.5 | 30 | 28.5 | 35 | 16 | 40360 | ||
| FDK 100.140 | 100 | 140 | 66 | 5 | 5.5 | 33 | 31.5 | 39 | 16 | 25920 | ||
| FDL 100.140 | 100 | 140 | 102 | 5 | 5.5 | 33 | 31.5 | 39 | 16 | 47520 | ||
| FDK 110.150 | 110 | 150 | 66 | 5 | 5.5 | 33 | 31.5 | 39 | 16 | 28510 | ||
| FDL 110.150 | 110 | 150 | 102 | 5 | 5.5 | 33 | 31.5 | 39 | 16 | 52270 | ||
| FDK 120.165 | 120 | 165 | 72 | 6 | 6.0 | 36 | 36.0 | 42 | 16 | 34560 | ||
| FDL 120.165 | 120 | 165 | 114 | 6 | 6.0 | 36 | 36.0 | 42 | 16 | 58750 | ||
| FDK 130.180 | 130 | 180 | 78 | 6 | 6.0 | 39 | 39.0 | 46 | 16 | 41180 | ||
| FDL 130.180 | 130 | 180 | 124 | 6 | 6.0 | 39 | 39.0 | 46 | 16 | 71140 | ||
| FDK 140.190 | 140 | 190 | 78 | 6 | 6.0 | 39 | 39.0 | 46 | 16 | 44350 | ||
| FDL 140.190 | 140 | 190 | 124 | 6 | 6.0 | 39 | 39.0 | 46 | 16 | 80640 | ||
| FDK 150.200 | 150 | 200 | 78 | 6 | 6.0 | 39 | 39.0 | 46 | 16 | 47520 | ||
| FDL 150.200 | 150 | 200 | 124 | 6 | 6.0 | 39 | 39.0 | 46 | 16 | 86400 |
