Built for durability, the MSW series ensures robust locking and effortless assembly in high-stress, dynamic environments.
Can be freely, infinitely and exactly positioned. Reliable locking without additional grooves or locking plates. Quick and precise assembly and disassembly.
| Product ID | 3D CAD | ød₁ (mm) [ISO-5H] | ød₂ (mm) [c11] | D6 Dia Mm | øh (mm) | Clamping Screw (ISO 4762) | Clamping Screw Mₐ (Nm) | No Clamping Screws | Calc Factor A (mm) | Calc Factor B (N) | Breaking Load (kN) | Breakaway Torque (Nm) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MSW 20.28 | M20x1.5 | 42 | 42 | 28 | M4 | 2.9 | 4 | 1.344 | 1560 | 194 | 40 | ||
| MSW 20.40 | M20x1.5 | 52 | 52 | 40 | M4 | 2.9 | 4 | 1.344 | 936 | 375 | 42 | ||
| MSW 25.28 | M25x1.5 | 47 | 47 | 28 | M4 | 2.9 | 4 | 1.633 | 1560 | 245 | 54 | ||
| MSW 25.40 | M25x1.5 | 62 | 62 | 40 | M4 | 2.9 | 4 | 1.633 | 936 | 470 | 59 | ||
| MSW 30.28 | M30x1.5 | 52 | 52 | 28 | M4 | 2.9 | 4 | 1.921 | 1560 | 295 | 68 | ||
| MSW 30.44 | M30x1.5 | 68 | 68 | 44 | M4 | 2.9 | 4 | 1.921 | 936 | 655 | 83 | ||
| MSW 35.28 | M35x1.5 | 60 | 60 | 28 | M4 | 2.9 | 4 | 2.210 | 1560 | 346 | 83 | ||
| MSW 35.44 | M35x1.5 | 73 | 73 | 44 | M4 | 2.9 | 4 | 2.210 | 936 | 767 | 97 | ||
| MSW 40.28 | M40x1.5 | 65 | 65 | 28 | M4 | 2.9 | 6 | 2.500 | 1560 | 398 | 134 | ||
| MSW 40.44 | M40x1.5 | 75 | 75 | 44 | M4 | 2.9 | 6 | 2.500 | 936 | 878 | 139 | ||
| MSW 45.28 | M45x1.5 | 70 | 70 | 28 | M4 | 2.9 | 6 | 2.789 | 2340 | 443 | 149 | ||
| MSW 45.44 | M45x1.5 | 90 | 90 | 44 | M4 | 2.9 | 6 | 2.789 | 1404 | 982 | 171 | ||
| MSW 50.32 | M50x1.5 | 75 | 75 | 32 | M4 | 2.9 | 6 | 3.079 | 2340 | 642 | 167 | ||
| MSW 50.46 | M50x1.5 | 95 | 95 | 46 | M4 | 2.9 | 6 | 3.079 | 1404 | 1168 | 204 | ||
| MSW 55.46 | M55x1.5 | 100 | 100 | 46 | M5 | 6.0 | 6 | 3.369 | 2286 | 1208 | 326 | ||
| MSW 60.46 | M60x1.5 | 100 | 100 | 46 | M5 | 6.0 | 6 | 3.655 | 2286 | 1321 | 438 | ||
| MSW 65.46 | M65x1.5 | 110 | 110 | 46 | M5 | 6.0 | 6 | 3.948 | 2286 | 1433 | 386 | ||
| MSW 70.46 | M70x1.5 | 115 | 115 | 46 | M5 | 6.0 | 6 | 4.238 | 2286 | 1551 | 390 |
