Fixed Jaw Dovetail Vises

Fixed Jaw Dovetail Vises

Modular Workholding Solutions

Key Features
Exposes up to five faces for open and efficient machining
Quick and easy precision bushing holes and two precision locating screws
Reduced scrap costs
Mounting for a 2" grid system uses standard ½"-13 SCHS
Designed to hold pre-marchined parts at a 15º angle

*Metric locating and mounting holes available upon request.

Fixed Jaw Dovetail Vises

Technical Specifications

Fixed Jaw Dovetail Vises
Showing 10 of 10 models
Loading...
Product ID3D CADBuy OnlineA (in)B±.002 (in)C (in)D (in)E±.0005 (in)F±.0005 (in)Weight (lbs)Jaw Quantity
AMF-59778-54.102.454.0003.821.054.00132
AMF-59778-84.103.954.0003.821.054.00154
AMF-59778-124.105.954.0003.821.058.00206
AMF-59778-164.107.954.0003.821.0512.00248
AMF-59778-244.1011.954.0003.821.0520.003112
AMF-59779-55.102.455.0004.821.554.00362
AMF-59779-85.103.955.0004.821.554.00424
AMF-59779-125.105.955.0004.821.558.00486
AMF-59779-165.107.955.0004.821.5512.00618
AMF-59779-245.1011.955.0004.821.5520.007212
0 models selected

Your Selection

Each model below is routed to the best next step based on availability.

Setup Time Calculator

How Much Is Setup Time Costing You?

Every changeover means idle spindle time. Multi-part fixturing slashes setup frequency — so your machines spend more hours cutting and less time waiting.

Your Machines
$
The Setup Problem
min
%
Annual Cost of Fixture Changeovers
1,500 hrs
Spindle Hours Lost to Setup / Year
$263K
Annual Lost Production Value
$131K
Recoverable with Workholding
See Full ROI Breakdown

Based on 250 working days/yr. Multi-part fixturing reduces changeover frequency so your spindle spends more time cutting.
