Fixture Clamps

Quality is built on a precision foundation

Mitee-bite fixture clamps are simple, cost-effective edge clamps that deliver excellent holding power in a compact format. With a single socket-head cap screw, these clamps push against the workpiece and pull it tightly against locating stops or a fixture base. They're a go-to solution for basic workholding setups, second operations, or rapid prototyping when minimal clamp height and fast changeovers are required.

Key Features
Simple Design	One-screw actuation for fast part changes
Compact	Maximizes machining envelope and part density
Durable Construction	Heat-treated alloy components withstand heavy use over time
Low Cost	Great for a budget-conscious shop or high-volume fixtures
Modular Placement	Mounts directly to fixture plates or t-slots

Notes:

Body Mounting Screw not included
Only Smooth jaw will have relief cut
*Body diameter
**Clamp Jaw Drive Screw and Retaining Ring Included.

Overview Catalog

Learn about our full workholding line including CNC tombstones, workholding systems, Build on the Rock partners, and custom fixturing solutions.

Capabilities Brochure

Our AMROK capabilities PDF offering a brief overview of our workholding product selection.

Request a Quote

Fixture Clamps

Technical Specifications

Showing 21 of 21 models

Loading...

Product ID	Units	A	B	C	D	E	F	G	Torque Max	Holding Force	Clamp Pack	Material	Replacement Cam Screw	Replacement Hex Washer
10201	Inch	5/16 -18 in	3/16 in	0.040 in	0.812 in	0.180 in	0.460 in	0.400 in	8.3 ft lbs	800 lbs	12	Brass	10367	10584
10202	Inch	8 - 32 in	5/64 in	0.030 in	0.312 in	0.110 in	0.350 in	0.150 in	1.5 ft lbs	205 lbs	10	Brass	10363	10580
10203	Inch	1/4 - 20 in	1/8 in	0.040 in	0.625 in	0.190 in	0.470 in	0.308 in	6.2 ft lbs	800 lbs	4	Stainless Steel	10364	10583
10204	Inch	1/4 - 20 in	1/8 in	0.040 in	0.625 in	0.190 in	0.470 in	0.308 in	6.2 ft lbs	800 lbs	10	Brass	10365	10582
10205	Inch	5/16 -24 in	3/16 in	0.040 in	0.812 in	0.180 in	0.460 in	0.400 in	8.3 ft lbs	800 lbs	12	Brass	10369	10584
10206	Inch	3/8 -16 in	3/16 in	0.050 in	0.812 in	0.250 in	0.710 in	0.400 in	20.8 ft lbs	2000 lbs	10	Brass	10371	10586
10207	Inch	10 - 32 in	3/32 in	0.040 in	0.500 in	0.160 in	0.340 in	0.250 in	2.5 ft lbs	350 lbs	10	Brass	10366	10587
10208	Inch	1/2 -13 in	5/16 in	0.100 in	1.000 in	0.375 in	0.900 in	0.500 in	65.0 ft lbs	4000 lbs	8	Brass	10373	10588
10210	Inch	5/8 -11 in	3/8 in	0.100 in	1.187 in	0.500 in	10.125 in	0.590 in	100.0 ft lbs	6000 lbs	4	Brass	10375	10592
10213	Inch	5/16 -18 in	3/16 in	0.040 in	0.812 in	0.250 in	0.460 in	0.400 in	8.3 ft lbs	800 lbs	4	Stainless Steel	10368	10585
10214	Inch	8 - 32 in	5/64 in	0.030 in	0.312 in	0.110 in	0.350 in	0.150 in	1.5 ft lbs	205 lbs	4	Stainless Steel	10362	10581
50204	Metric	M4	3 mm	0.76 mm	7.93 mm	2.80 mm	9.60 mm	3.80 mm	2.0 Nm	910 N	10	Brass	50363	10580
50205	Metric	M6	4 mm	1.01 mm	15.86 mm	4.75 mm	11.20 mm	7.80 mm	9.0 Nm	3558 N	4	Stainless Steel	50364	10583
50206	Metric	M6	4 mm	1.01 mm	15.86 mm	4.75 mm	11.20 mm	7.80 mm	9.0 Nm	3558 N	10	Brass	50365	10582
50207	Metric	M8	5 mm	1.01 mm	20.60 mm	6.35 mm	15.00 mm	10.15 mm	11.0 Nm	3558 N	4	Stainless Steel	50366	10585
50208	Metric	M8	5 mm	1.01 mm	20.61 mm	4.55 mm	15.00 mm	10.15 mm	11.0 Nm	3558 N	12	Brass	50367	10584
50210	Metric	M10	7 mm	1.27 mm	20.61 mm	6.35 mm	19.00 mm	10.15 mm	28.0 Nm	8895 N	10	Brass	50369	10586
50212	Metric	M12	8 mm	2.03 mm	25.38 mm	9.52 mm	22.80 mm	12.70 mm	88.0 Nm	17790 N	8	Brass	50371	10590
50214	Metric	M4	3 mm	0.76 mm	7.93 mm	2.80 mm	9.60 mm	3.80 mm	2.0 Nm	910 N	4	Stainless Steel	50361	10581
50216	Metric	M16	12 mm	2.54 mm	30.13 mm	12.70 mm	28.50 mm	15.00 mm	125.0 Nm	26680 N	4	Brass	50373	10592
50218	Metric	M8	5 mm	1.01 mm	20.61 mm	4.55 mm	15.00 mm	10.15 mm	11.0 Nm	3558 N	bulk	Brass	502181	10584
