Uniforce Clamps (Machinable)

Uniforce Clamps (Machinable)

Quality is built on a precision foundation

Machinable Uniforce clamps offer the flexibility of customization for complex geometries, contoured parts, or soft materials with the power of the original Uniforce clamp. The aluminum inserts are easy to modify while maintaining the power and compact form the Uniforce is known for.

Key Features
Custom Jaw Geometry Machine to match your part's shape
Non-Marring Contact Great for finished surfaces or soft materials
Tight Footprint Keeps Z-clearance and tool access optimized
Back-to-Back Clamping Ensures consistent placement on both sides
Fast Changeover Easily swap jaws for different workpiece runs
Uniforce Clamps (Machinable)

Technical Specifications

Uniforce Clamps (Machinable) Drawing
Showing 10 of 10 models
Loading...
Product ID3D CADPart No With Locking PlatePart No Without Locking PlateABCDEFGHIMax TorqueHolding ForceReplacement SteelReplacement Channel
50060050600501.125 in0.50 in0.62 in0.420 in0.25 in0.18 in0.400 in2-568-322.5 ft lbs500 lbs6031060140
75060075600751.500 in0.75 in0.94 in0.632 in0.37 in0.26 in0.625 in6-321/4-2010.0 ft lbs1500 lbs6032060125
100060100601002.000 in1.00 in1.25 in0.820 in0.50 in0.39 in0.812 in6-325/16-1819.0 ft lbs2000 lbs6033060135
150060150601503.000 in1.50 in1.87 in1.215 in0.75 in0.62 in1.200 in10-321/2-1328.3 ft lbs3500 lbs6034060160
200060200602004.000 in2.00 in2.50 in1.625 in1.00 in0.80 in1.625 in1/4-205/8-1155.0 ft lbs6000 lbs6035060180
500800508005528.6 mm12.7 mm15.7 mm10.67 mm6.3 mm4.6 mm10.16 mmM2M43.40 Nm2225 N6031060140
750800758008038.1 mm19.1 mm23.9 mm16.05 mm9.4 mm6.6 mm15.87 mmM4M613.50 Nm6675 N6032060125
1000801008010550.8 mm25.4 mm31.8 mm20.83 mm12.7 mm9.9 mm20.62 mmM4M825.00 Nm8900 N6033060135
1500801508015576.2 mm38.1 mm47.5 mm30.86 mm19.1 mm15.7 mm30.48 mmM5M1238.40 Nm15575 N6034060160
20008020080205101.6 mm50.8 mm63.5 mm41.28 mm25.4 mm20.3 mm41.28 mmM6M1674.60 Nm26700 N6035060180
